RPR 550IS Series
Page 2A - 2 TM1188 Issue B
Table 1: Engineering States
ENGINEERING
STATE
DESCRIPTION
E0 Bytes 0-3 of EEPROM displayed
E1 Bytes 4-7 of EEPROM displayed
E2 Bytes 8-B of EEPROM displayed
E3 Bytes C-F of EEPROM displayed
E4 Address displayed
E5 Quiet tone
E6 Normal tone
E7 Out-of-range buzz
E8 Vibrate
E9 Speech channel open
E10 All segments displayed
Engineering Mode Characters
4. Engineering states E0-E3 contain 16 hexadecimal numbers representing eight bit binary
words stored in the EEPROM. Interpretation of the binary words relating to the first two
screens indicate the options programmed into the pager.
5. To establish the programmed options convert each hex digit to its four bit binary number
using Table 2. Align these groups of binary numbers to their respective positions in Table 3
and extract the programmed options as shown in Table 4. See below for sample engineering
mode displays of the first two screens.
E0:90 15 6C E6 E1:43 85 E1 03
