Munire 6299 - Step 2: Mattress Support Height Adjustment

- Remove the allenbolt 1 1/4” (30 mm) (J), spring washer (W) and nut 3/4” (20 mm) (L) on the mattress spring.
- Move Mattress spring to the lowest position as shown in FIG.2.
- Attach the (J) and nut (L) on the lowest hole of side frame.
- Final position as shown in FIG.3.
allenbolt 1 1/4” (30 mm) , spring washer (W) 3/4” (20 mm)
L. Nut 3/4” (20 mm) ( 4 pcs )
(N)
(2 pcs)
W. Spring Washer (4 pcs)
these hardware are included in the CRIB
Lowest
Position
(J)
(W)
(N)
(L)
J. Allenbolt 1 1/4 (30 mm) (4 pcs)”
02-A-SUTM01-00
