(M) Barrel Nut 1 (4 pcs)” (25 mm)
( F ) Allenbolt 2 3/4 (70 mm) (8 pcs)”
( H ) Allenbolt 2” (50 mm) (2 pcs)
( J ) Allenbolt 1 1/4 (30 mm)
(4 pcs)
”
( L ) Nut 3/4 (8 pcs)” (20 mm)
( W ) Spring Washer (16 pcs)
Make sure the bolts are tightly locked against the washers during assembly.
(Please add an extra ½ revolution to all the bolts when using spring washer after tightening)
(N) Allenkey (2 pcs)
( length may vary)
( O ) Allenbolt 1 1/2” (40 mm)
(2 pcs)
02-A-SUCM01-00
To Next Page
