L. Nut 3/4 (20 mm) (4 pcs)”
- Attach mattress spring (E) to Side board as shown in FIG.3.
- Secure with allenkey (N).
- See FIG. 4 for height adjustment
- Make sure the mattress spring is leveled after assembly.
2
W. Spring Washer (4 pcs)
N. Allenkey (2 pcs)
FIG. 4
Highest
Position
Middle
Position
Lowest
Position
(J)
(N)
(W)
FIG. 3
(W)
(J)
(N)
(L)
J. Allenbolt 1 1/4 (30 mm) (4 pcs)”
02-A-SUCM01-00
