- Insert allenbolt 1 ½" (40 mm) (O) & spring washer (W) through the top holes in side board
into the threaded holes footboard (B). FIG. 5
FIG. 6
- Insert allenbolt 2" (H) & spring washer (W) through the bottom holes in side board
into the threaded holes footboard (B).
- Tighten all bolts and nuts with allenkey (N)
(50 mm)
N
3
H. Allenbolt 2” (50 mm) (2 pcs)
W. Spring Washer (4 pcs)
(N)
(H)
(W)
(O)
(W)
(B)
O. Allenbolt 1 1/2” (40 mm) (2 pcs)
02-A-SUCM01-00
FIG. 5
FIG. 6
Inline
and have
no gap
