TRIO
RPS
TRIO RPS serves a
s a second
static press
ure sensor for the TRI
O Controller. T
he followin
g section d
etails
the installa
tion.
TRIO supports up to
two static pressure sensors
,
one built i
n and one external.
Install t
he RPS in the
second room.
Figure
25
: RPS W
iring
Numbe
r
Function
1
S port. Raise th
e correspond
ing S3 dip
switch.
2
COM port
3
12V
4
Shield wire
Figure
26
: RPS W
iring Sc
hem
atic
29
31
