Accessories for the product can be found on page 20.
3.1 Equipment
The wire feed unit is supplied with connection set (5m), instruction manual and
stickers.
4 TECHNICAL DATA
T ransmatic 4C
Power supply 42 V 50--60 Hz
Power requirement 336 VA
Motor current I
max
3.5 A
Settings data
Wire feed speed
Burnback time
1.5--22.0 m/min
0-- 0.7 s
Gun connection EURO
Max. diameter wire bobbin 300 mm
Wire dimension
Fe
Ss
Al
Cored wire
0.6--1.6 mm
0.6--1.2 mm
1.0--1.6 mm
0.8--1.6 mm
Weight 13.2 kg
Dimensions (l x b x h) 569 x 259 x 355 mm
Shielding gas
max pressure
Gases for MIG/MAG welding
5 bar
Maximum permissible load at
60% duty cycle
100% duty cycle
365 A
280 A
Enclosure class
basic version
with sealed bobbin holder*
with MarathonPact
IP2X
IP23
IP23
* Accessories, see page 20.
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid
objects or water. Apparatus marked IP2X are intended for indoor use.
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid
objects or water. Equipment marked IP23 is designed for indoor and outdoor use.
Duty cycle
The duty cycle refers to the time as a percentage of a ten--minute period that you can weld at a cer-
tain load without overloading. The duty cycle is valid for 40˚C.
