Hardware Installation
The following instructions will guide you through installing the PowerView display.
Inspecting Package Contents
Before attempting to install the product, it is recommended that you ensure all parts are
accounted for and inspect each item for damage (which sometimes occurs during shipping).
The items included in the box are:
PV780 unit
Installation kit – P/N 78-00-0638 includes:
• 4 ea. machine screws and flat washers
• 4 Nylock nuts
• Installation & Operations manual web reference insert
Dash-Mounted Installation
Tools needed.
• Drill with 5/32” size bit
• Jig Saw
• Wrench or socket 6-32 Nylock nuts (provided) to studs
Preparing the Dash
Determine the location of the PowerView in the dash. Use the Installation Template (included
at the end of the manual) as a guideline to cut a hole in the dash to the specified dimensions.
Drill holes where indicated on the template for the mounting screws.
NOTE: When using the paper template from the manual, if you downloaded this
document from the FW Murphy website, be aware that the pdf file may not
automatically print to scale. When submitting the file for print, you will need to
select “None” for Page Scaling. Check the accuracy of the printed template by
verifying the measurements labeled on the template are correct.
If this manual was supplied with your product, the template will be correct.
Section 78 00-02-0860
2013-08-29 - 1 -
