Hardware Installation
The following instructions will guide you through installing the PV485 display.
Inspecting Package Contents
Before attempting to install the product, it is recommended that you ensure all parts are
accounted for and inspect each item for damage (which sometimes occurs during shipping).
The items included in the box are:
Installation kit – P/N 78-00-0783 includes:
4 (8-32) mounting studs
4 (8-32) Keps Nuts
1 small bag
Tools needed.
Drill with 3/16” size bit
Jig Saw
Wrench or socket for (8-32) Keps nuts
Dash-Mounted Installation
Preparing the Dash
Determine the location of the PowerView 485 in the dash. Use the Installation Template
(included at the end of the manual) as a guideline to cut a hole in the dash to the specified
dimensions. Drill holes where indicated on the template for the mounting screws.
NOTE: When using the paper template from the manual, please be aware that if
you downloaded this document from the Murphy by Enovation Controls website,
the pdf file may not automatically print to scale. When submitting the file for print,
you will need to select “None” for Page Scaling. Check the accuracy of the
printed template by verifying the measurements labeled on the template are
correct.
If this manual was supplied with your product, the template will be correct.
