If you are new to Create Space, follow the first few steps in Section 1.9.2 to add the ARTisan
to Create Space.
Click on OK and LXi Production Manager will open.
The Cut/Plot window will also have opened. On the General tab, select SAVE to FILE from the
Send mode drop-down menu:
When you have made any necessary changes to the file size, copies, rotation, etc., click the Send
button at the bottom right of the Cut/Plot window.
A window will open prompting you to select the desired location to save the .PLT file. Browse to the
installed flash drive and save the file after entering a new name. Go to Section 1.9.8.
Change the Port connection by right clicking on the ARTisan in the Production Manager list,
and selecting Change Port.
In the Change Port window, select FILE and then complete other options, as preferred:
NOTE: if you will continually be using the USB Flash Drive as your method of sending files to the ARTisan:
USB Flash Drive Setup in Create Space
1.9.7
Using the UDISK (USB thumb drive) option involves saving a .PLT file containing the cut design and
some or all of the cut settings. This file can then be opened directly onto the ARTisan and cut.
Remember that with this option, once the file is saved to the thumb drive, the design is locked in
and cannot be edited.
