Basic problem solving with an amplier is similar to trouble shooting other electrical or electronic
equipment. Always check the most obvious possible causes rst, such as the following examples:
No power Power supply not switched on.
Power plug is not fully inserted into
rear power socket.
Check power supply s plugged in and
switched on.
Plug in securely.
No sound Wrong connections between input
source and the LX
2
-LPS.
Wrong connections between
the LX
2
-LPS and the following
component.
Check audio input lead connections.
Check audio ouput connections.
Hum Audio connector plug not fully
pushed in.
Turntable earth not connected.
Earth loop within system
(may not be apparent with other line
level sources).
Inset plug securely and check
leads.
Try connection turntable ground
lead to ground post on LX
2
-LPS.
Disconnect turntable earth
connection. Not all setups require
turntable to be earthed.
MM MC
Specications Input impedance
Input sensitivity
Total harmonic distortion
Signal / noise ratio
Input overload margin
47KΩ
3.0mV
0.01%
>80dB
15dB
100Ω
300µV
0.01%
>70dB
22dB
General RIAA response
Power requirement
+/-0.25dB
12 - 24V 100mA regulated
Connections Moving Magnet Input
Moving Magnet loading
Moving Coil Input
Moving Coil Loading
Power Input
1pr RCA sockets
1pr RCA sockets
1pr RCA sockets
1pr RCA sockets
DC Jack (1.3mm inner
pin, outer Θ 3.5mm)
Dimensions Length
Width
Height
197mm
172mm
46.50mm
Including terminals
Including feet
Weight Unit alone
Unit with packing
1.05Kg
1.50Kg
Accessories
(supplied)
Power Supply 12v DC 500mA
