MW MOUNTS Large Full Motion - Step 4 & 5: Attaching Assemblies; Attach Mount Assembly to Wall Plate; Attach Monitor Plate to Arm Assembly

STEP 4- ATTACH MOUNT ASSEMBLY TO WALL PLATE
P10
Position Arm Assembly to desired lateral
position on wall plate for optimum placement of
Flat Panel. Secure Arm Assembly to Wall plate
using screws removed from Step 2.
C
A
STEP 5- ATTACH UNIVERSAL MOUNT PLATE TO ARM ASSEMBLY & WALL
PLATE
A
B
Heavy, Assistance
Required
TRES LOURD ! Cette etape
requiert deux personnes
!PESADO! Necesitara ayuda para
realizar esta operacion
C
A1
