MW MOUNTS Large Full Motion - Hardware Product Numbers; Product Component Parts; Universal Adapter Range

P3
HARDWARE PRODUCT NUMBERS
PRODUCT COMPONENT PARTS
SECURITY
ALLEN
WRENCH
4 mm
6 5 7
10
5mm
SPACER
X 8
2
1
3
M5 x 12
X 4
M6 x 15
X 4
M8 x 15
X 4
M5 x 25
X 4
M6 x 25
X 4
M8 x 25
X 4
4
8
M4 x 12
X 4
M4 x 25
X 4
13
11
8 mm LAG
BOLT
X 4
12
STEEL
WASHER
X 4
M6 X 5/8”
WRENCH
X 1
M6
WASHER
X 2
M6
ACORN
NUT
X 2
9
SQUARE
WASHER
X 4
Product Components
Contents Qty
Description
A 1 Wall Plate
B 1 Universal Monitor Plate
C 1 Arm Assembly
ANCHOR
X 4
A
B
Universal Adapter Range
Minimum: 200mm x 100mm (W X H)
Maximum: 600mm x 400mm (W X H)
C
A4
A1
A3
A2
