MW MOUNTS Large Full Motion - Step 2: Prepare Arm Assembly for Wall Mounting; Removing Arm Assembly from Wall Plate

P7
Prior to extending arms;
• Remove 2 Philips screws at top of
Arm Assembly .
• Remove 2 security screws at
bottom of Arm Assembly with
security Allen wrench.
Note- 2 Philips screws and 2 security
screws will be used in Step 4 to reattach
arm assembly to wall mount.
STEP 2- PRIOR TO EXTENDING ARMS REMOVE ARM ASSEMBLY FROM WALL PLATE
Remove Arm Assembly by gently
lifting vertically off Wall Plate. Wall
Plate is now ready to attach to wall surface
(Step 3).
A1
A1
