mycom 200MUD

Chapter 7 Related Documents
UD-series Screw Compressor 7.2 Parts Configuration Table 250*UD
7-23
P/N
Part Name
Code No.
Remarks
Q’ty.
216
2
Gasket, Lubrication Oil Supply Flange CR72000-025N MYK25A 1
217
3
Hexagon Head Bolt NB111012-035 M12X35 4
235 Spacer, Discharge Flange FX101-250 250*** 1 (*UD)
236 Gasket, Discharge Flange Spacer CS23600-250N 250*** 1 (*UD)
237 Torsional Slip Washer CS23700-250 250*** 2
246 Guide, Unloader Slide Valve CS24600-250 250*** 1
247 Hexagon Socket Head Cap Screw NB35408-090 M8X90 4
248
Spring Washer for Hexagon Head Cap
Screw
ND330-08 M8 4
249 Alignment Pin NE2008-080 φ8X80 2
250
Thrust Washer
CS25000-250
250***
2
251 Flange for Electromizer CS71400-050 MYK50A Male 1
252 Gasket, Flange for Electromizer CR72000-050N MYK50A 1
253 Hexagon Head Bolt NB111016-045 M16X45 4
255 Gasket, Flange for Aquamizer CR72000-032N MYK32A 1
256
A
Hexagon Head Bolt NB111012-040 M12X40 4
267
B
Spring Washer fro Hexagon Head Cap
Screw
ND330-12 M12 4
432
A
O-ring PA12-130 JISB2401 1A G130 4
433
B
O-ring PA12-130 JISB2401 1A G130 4
528 Sleeve, Oil Seal CS52809-250VD 250V** 1
529 Set Screw NA83606-008 M6X8 2
605 Plug NF06-025 R 1" 1
607
A
Plug NF06-008 R1/4 1
607
B
Plug NF06-008 R1/4 1
715 Blind Plate for Aquamizer CS71500-032 32A 1
744 O-ring PA12-070 JISB2401 1A G70 1
 The part code of the O-ring is the one assigned to NBR which is standard material.
When the material of the O-ring is other than NBR, a different part code is used for
each material.
If you are using O-rings made from other than the standard material, please contact
MAYEKAWA when placing an order.
 The Code No. of parts shown in parentheses below is applied to the product until the
end of November, 2014:
(P/N 120 Unloader Indicator Assembly, P/N 125 Micro-Switch, P/N 129 Potentiometer)
 For the Code No. of new type indicator part, refer to the separately dedicated
Instruction manual for it.
