mycom 3225MSC User Manual

2202MYJE-MY-C8-N_2018.02.
Chapter 5 Maintenance and Inspection
Compound 2-stage Screw Compressor 3225**C 5.3 Compressor Disassembly Preparation
5-9
P/N
Part Name
Code No.
Remarks
Q’ty.
73-1
O-ring JIS B 2401 P44
PA11-044
1
73-2
O-ring JIS B 2401 G35
PA12-035
1
75-1
O-ring JIS B 2401 G150
PA12-150
1
75-2
O-ring JIS B 2401 G170
PA12-170
1
78
Ball Bearing, Indicator Cam #6000
CS07800-200
2
79
Snap ring C type External S10
NG12-010
2
82
V-ring, Indicator Cam VH10 NBR
CS08200-200B
2
86
O-ring JIS B 2401 G30
PA12-030
1
89-1
O-ring JIS B 2401 P24
PA11-024
2
89-2
O-ring JIS B 2401 P20
PA11-020
2
93-1
Gasket, Suction Flange (1)
CS71200-350N
JIS 20K 350A(14")
1
93-2
Gasket, Suction Flange (2)
CS71200-200N
JIS 20K 200A(8")
1
96-1
Gasket, Discharge Flange (1)
CS71200-200N
JIS 20K 200A
1
96-2
Gasket, Discharge Flange (2)
CS71200-150N
JIS 20K 150A
1
100
Mechanical Seal Assembly BBS-E
CS10002-320EBS
1
125-1
Set of Micro-switch (1)
CS1259-C
1
125-2
Micro-switch (2)
CS12500-200
2
129-1
Potentiometer (1) 1612 1k with Wire
CS1299-J
To be replaced if any
abnormality is found.
1
129-2
Potentiometer (2) 200-1K with Wire
CS1299-E10
1
202-1
Bevel Gear 1612D ID 6 mm
CS20100-1612C6
To be replaced if any
abnormality is found.
2
150
O-ring JIS B 2401 G220
PA12-220
2
-
Gear Coupling Assembly (Current Type)
CS1519-M
To be replaced if any
abnormality is found.
1
159
Knurled Cup Point Socket Set Screw
NA83610-025
To be replaced if any
abnormality is found.
1
160
Lock Nut AN15, Drive Hub
NG31-015
To be replaced if any
abnormality is found.
1
161
Lock Washer AW15
NG32-015
1
165
O-ring JIS B 2401 P40
PA11-040
1
197
O-ring JIS B 2401 P58
PA11-058
1
216-1
Gasket, Lubricating Oil Inlet Flange (1)
CS71200-040N
JIS 20K 40A
1
216-2
Gasket, Lubricating Oil Inlet Flange (2)
CS71200-025N
JIS 20K 25A
1
219
Gasket, Oil Injection Inlet Flange
CS71200-020N
JIS 20K 20A
1
237-1
Tortional Slip Washer (1)
CS23700-320
2
237-2
Tortional Slip Washer (2)
CS23700-250
2
328
O-ring JIS B 2401 P46
PA11-046
1
351
Gasket, Balance Piston Lubricating Oil
Outlet Flange
CS71200-020N
JIS 20K 20A
1
354
Gasket, Bearing Cover Lubricating Oil
Outlet Flange
CS71200-032N
JIS 20K 32A
1
357
Gasket, Main Rotor Casing Oil Return
Flange
CS71200-032N
JIS 20K 32A
1
421
O-ring JIS B 2401 P46
PA11-046
2(*SC)
(*MC)
431
O-ring JIS B 2401 P140
PA11-140
1 (M*C)
432-1
O-ring JIS B 2401 G165
PA12-165
4
432-2
O-ring JIS B 2401 G130
PA12-130
4
433-1
O-ring JIS B 2401 G165
PA12-165
4
