Chapter 5 Maintenance and Inspection
Compound 2-stage Screw Compressor 3225**C 5.3 Compressor Disassembly Preparation
5-10
P/N
Part Name
Code No.
Remarks
Q’ty.
433-2
O-ring JIS B 2401 G130
PA12-130
4
528
Oil Seal Sleeve with O-ring
CS52809-320VD
1
744
O-ring, Oil Seal Sleeve JIS B 2401 G90
PA12-090
1
-
Coupling Element
To be replaced if any
abnormality is found.
-
-
O-ring Set 3225C NBR
CS7109-0M
-
-
Gasket Set 3225C
CS7118-0M
-
In case of replacing the main/side bearings of No.27 and No.28, it is not necessary to prepare the
O-rings of No.432 and No.433 because the main/side bearings have the O-rings.
The sizes of O-ring No.432-2 and No.432-2 have been changed to G130 from G135 in October 2012
as a design modification.
● The part code of the O-ring is the one assigned to NBR which is standard material.
When the material of the O-ring is other than NBR, a different part code is used for
each material.
If you are using O-rings made from other than the standard material, please contact
us when placing an order.
