Chapter 2 Compressor Specifications and Configuration
Screw Compressor i-series 2.4
Configuration of Compressor
2-27
P/N Part name Code No. Remarks Qty
33
Sleeve, Balance Piston
CS03300-I125
i125
1
34
Spring pin
NE3206-015
FM160 (Φ6×15)
1
35
O-ring
PA11-016
JIS B 2401 P16
1
38-1
Thrust Bearing M
CS03800-I125MP
Shared with i125M,FM11S
1
38-2
Thrust Bearing F
CS03800-125FP
Shared with i125F,125
1
39-1
Lock Nut
NG31-008
AN8
1
39-2
Lock Nut
NG31-009
AN9
1
40-1
Lock Washer
NG32-008
AW8
1
40-2
Lock Washer
NG32-009
AW9
1
41-1
Spacer, Thrust Bearing Outer Race M
CS25000-FM11S
FM11S Thrust Washer
1
41-2
Spacer, Thrust Bearing Outer Race F
CS04100-I125F
i125F
1
42-1
Spacer, Thrust Bearing Alignment M
CS04200-I125M
i125M
1
42-2
Spacer, Thrust Bearing Alignment F
CS04200-125
125***
1
43-1
Thrust Bearing Gland M
CS04300-I125M
i125M
1
43-2
Thrust Bearing Gland F
CS04300-I125F
i125F
1
45
Hexagon Head Bolt
NB111008-035
M8X35-10.9
SCM435
8
46
Spring Washer
ND320-008
M8
8
48
Retainer, Oil Seal
CS04800-125
125***
1
49
O-ring
PA12-085
JIS B 2401 G85
1
50
Oil Seal
CS05000-125D
125*** Rareflon
1
51 Seal Cover CS05100-125BBS
Shared with 125*** seal pot
specifications
1
52
Gasket, Seal Cover
CS05200-125N
125***
1
53
Hexagon Socket Head Cap Screw
NB35406-020
M6×20 SCM435
8
58
Hexagon Socket Head Cap Screw
NB35408-030
M8X30 SCM435
12
91
Coupling Key
CS09100-125
125L**
1
92
Suction Flange with hole
CS74000-100
MYK 100A (Male)
1
92
Suction Cover Flange
CS71400-P100
MYK 100A(Male)
1
93
Gasket, Suction Flange
CR72000-100N
MYK 100A
1
94
Hexagon Head Bolt, Suction Flange
NB12022-060
M22×60 SCM435
S:4 L:8
95
Discharge Flange with hole
CS71400-065CDMK
MYK 65CD (Male)
1
235
Discharge Flange Spacer
FX101-125
65CD for 125
1
236
Gasket, Suction Flange Spacer
CS23600-125N
65CD for 125
1
96
Gasket, Discharge Flange
CS23600-125N
MYK 65CD
1
97
Hexagon Head Bolt, Discharge Flange
NB12016-045
M16×45 SCM435
S:4 L:8
100
Mechanical Seal Assembly
CS10002-125EBS
BBSE
125***
1set
235-1
Motor Spacer
－
for NEMA Motor Flange
1
CS23500-I125IEC40
for IEC FF400
CS23500-I125IEC50
for IEC FF500
235-2
Plate, Motor Spacer
CS23510-I125
i125
2
－
for IEC FF400 (1), (2)
2
－
for IEC FF500 (1), (2)
2
235-3
Hexagon Socket Head Cap Screw
NB35406-010
M6×10 SCM435
8
237-1
Torsional Slip Washer M
CS23700-FM125M
FM125 M
1
