Chapter 2 Compressor Specifications and Configuration
Screw Compressor i-series 2.4
Configuration of Compressor
2-28
P/N Part name Code No. Remarks Qty
237-2
Torsional Slip Washer F
CS23700-125
125L**
1
250-1
Thrust Washer M CS04200-I125M
i125M Spacer, thrust
bearing alignment
1
250-2
Thrust Washer F
CS25000-125
125***
1
391 Unloader Piston CS39100-I160 i160* 2
392
Spring
CS39200-F125
FM125
2
393
Unloader Cover
CS39300-I160
i160*
2
395
Gasket, Unloader Cover
CS39500-I160
i160*
2
480
Strainer Element
CS48000-I160
i160*
1
481
Retainer, Strainer Element
CS48100-I125
i125
1
482
Hexagon Socket Head Cap Screw
NB35406-015
M6×15 SCM3
2
485
Check Valve Spring
CS48500-F125
FM125
1
486
Hexagon Nut
NC622-10
U-NUT M10
1
487
Plain Washer ND193-10
JISB1256 small-sized,
round-shaped 10-22H
1
488-1
Seat Stopper (1)
CS48800-F125
FM125
1
488-2
Seat Stopper (2)
CS48800-F1252
FM125
1
489
Valve Seat
CS48900-I125
i125
1
490
Valve Plate
CS49000-I125
i125
1
491
Check Valve Shaft
CS49100-I125
i125
1
495
O-ring
PA11-007
JIS B 2401 P7
1
533 Solenoid Valve
KF711-XOF1
SPOLAN XOF-120V
2
KF711-XOF2
SPOLAN XOF-240V
534
Nipple (High Pressure)
NN410-080
R3/8 Sch40 80L
2
535
Connection (L-type)
NJ3-0803NE
L-Φ8-R3/8 JO4060
2
536
Connection (L-type)
NJ3-0802KNNT
L-Φ8-R1/4 JO4050
2
538
Piping
QA11-08
Φ8 STS
2
546
Wave Washer
ND91-016
FM125 BW16
1
555
Angle Valve
NF042-0302N
R1/4×Rc1/4
2
795
Cover Plate, Discharge Flange
CS71500-I1251
i125 4.5x84D
１
795
Cover Plate, Suction Flange
CS71500-I1252
i125 4.5x123D
１
 The part code of the O-ring is the one assigned to NBR-70-1 which is standard
material. When the material of the O-ring is other than NBR, a different part code is
used for each material.
If you are using O-rings made from other than the standard material, please
contact MAYEKAWA when placing an order.
