Myson Touch 2 WiFi - Wiring Diagram: Touch 2 WiFi to UFH Wiring Centre

Touch 2 WiFi
Touch 2 WiFi
31
Wiring Diagram
Touch 2 WiFi to UFH Wiring Centre 230V & optional probe connections
A1A2RT1
-
RT2
LN
230VAC
REMOTE AIR PROBE
(Optional)
FLOOR PROBE
(Optional)
TC-M
A1A2RT1
-
RT2
LN
230VAC
REMOTE AIR PROBE
(Optional)
FLOOR PROBE
(Optional)
L N SL
TC-M
A1A2RT1
-
RT2
LN
230VAC
REMOTE AIR PROBE
(Optional)
FLOOR PROBE
(Optional)
L N SL
L
N
This product must only be installed by a qualified electrician
and comply with local installation regulations.
Zone 1
To thermal actuator
