N-Com B1 - Connecting the Battery

10
3.1. Removing the B1 system from the helmet
Proceed as follows to remove the B1 system from the helmet:
 Remove the cheek padding and the shell gasket;
Fig. 8
 Remove the keypad from the shell,
using a flat head screwdriver (or a
similar tool) to lever upwards in the
special hollow as shown in fig. 8.
Fig. 9
 Unhook the right and left clips from
the shell, levering upward using a flat
head screw (or a similar tool), as
shown in figure 9.
 Completely remove the B1 system from the helmet and re-install the cheek padding
and the gasket.
