15
Gigabit Fiber Transceiver (SFP) Characteristics
Fiber Length
550m* with 50/125 µm
275m @ 62.5/125μm
10km**
40km**
80km**
TX Power Min
-9.5dBm
-9.5dBm
-2dBm
0dBm
RX Sensitivity Max
-17dBm
-20dBm
-22dBm
-24dBm
Wavelength
850nm
1310nm
1310nm
1550nm
Assumed Fiber Loss
3.5 to 3.75 dB/km
0.45 dB/km
0.35 dB/km
0.25 dB/km
Laser Type
VCSEL
FP
DFB
DFB
*SX Fiber Optic Cable
** LX Fiber Optic Cable
Regulatory Approvals:
Safety: For use in Class I, Division 2, Groups A, B, C and D Hazardous Locations.
UL 508, Industrial Control Equipment.
ANSI/ISA-12.12.01-2007 for use in Class I and II, Division 2 and Class III Divisions 1 and 2
Hazardous (Classified) Locations Groups A, B, C, D. T4A.
cUL C22.2 No. 14-M05
cUL C22.2 No. 213-M1987 for use in Class I, Division 2 Hazardous Locations.
EMI: EN61000-6-4, EN55011 - Class A
FCC Title 47, Part 15, Subpart B - Class A
ICES-003 – Class A
EMS: EN61000-6-2
EN61000-4-2 (ESD)
EN61000-4-3 (RS)
EN61000-4-4 (EFT)
EN61000-4-5 (Surge)
EN61000-4-6 (Conducted Disturbances)
Warranty: 3 years from the date of purchase.
