(Revised 2011-04-15)
100 Series Industrial Ethernet Switches
The 100 Series Unmanaged Industrial Ethernet Switches support high speed layer 2 switching between
ports. This series of switches are housed in a ruggedized aluminum enclosure, and provide Category-5
compliant 10/100-BaseT connections for high performance network design, and hub/repeater upgrades.
All fiber products utilize the IEEE compliant SC or ST duplex connectors for fiber optic communications.
All 10/100Base-TX ports utilize the RJ45 shielded connectors.
The 102MC/MCE is a two-port unmanaged media converter that converts 10/100BaseTX copper to
100BaseFX full duplex fiber.
The 104TX, 105TX and 108TX are affordable and share a small footprint. Each switch is capable of auto
negotiating 10/100 Mb and half/full duplex communications. The five-port 105TX-SL offers the same
functionality and is distinguished by its ultra-slim enclosure.
The 105FX/FXE has 4 ports similar to the 104TX, plus additional multimode fiber optic up-link port(s), capable
of 2 Kilometers of 100 Mb communications for the FX models, and up to 80 Kilometers for the FXE models
without the use of repeaters.
The 106FX2/FXE2 has 4 10/100BaseTX RJ-45 auto sensing ports and 2 100BaseFX ports with ST or SC
connectors, capable of 2 Kilometers of 100 Mb communications for the FX models, and up to 80 Kilometers for
the FXE models without the use of repeaters.
The 110FX2/FXE2 has 8 10/100BaseTX RJ-45 auto sensing ports and 2 100BaseFX ports with ST or SC
connectors, capable of 2 Kilometers of 100 Mb communications for the FX models, and up to 80 Kilometers for
the FXE models without the use of repeaters.
The 111FX3/FXE3 has 8 10/100BaseTX RJ-45 auto sensing ports and 3 100BaseFX ports with ST or SC
connectors, capable of 2 Kilometers of 100 Mb communications for the FX models, and up to 80 Kilometers for
the FXE models without the use of repeaters.
The 112FX4/FXE4 has 8 10/100BaseTX RJ-45 auto sensing ports and 4 100BaseFX ports with ST or SC
connectors, capable of 2 Kilometers of 100 Mb communications for the FX models, and up to 80 Kilometers for
the FXE models without the use of repeaters.
The 114FX6/FXE6 has 8 10/100BaseTX RJ-45 auto sensing ports and 6 100BaseFX ports with ST or SC
connectors, capable of 2 Kilometers of 100 Mb communications for the FX models, and up to 80 Kilometers for
the FXE models without the use of repeaters.
The 116TX has 16 10/100BaseTX RJ-45 auto sensing. Each port is capable of auto negotiating 10/100 Mb and
half/full duplex communications.
Key Features
Full IEEE 802.3 & 100Base-FX Compliance
Extended Environmental Specifications
Support for Full/Half Duplex Operation
LED Link/Activity Status Indication
Autonegotiation, Autosensing Speed, Duplex, and Flow Control
Up to 3.2 Gb/s Maximum Throughput
Industry Standard 35mm DIN Rail Mounted Enclosure
