11
SPECIFICATIONS
All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter.
*: ±0,3 dB (20 Hz - 20 kHz)
Note: The RIAA response is consistentwith a pre-emphasis that is
rolled off at 50kHz by a second order filter,such as used in Neumann
cutting lathes.
GENERAL SPECIFICATIONS
LIJNINGANG/LUIDSPREKER UIT
Continu outputpower @ 4 Ohm and 8 Ohm
2 x 40 W (ref. 20 Hz-20 kHz THD 0,03%, both channel driven)
THD (20 Hz – 20 kHz)
<0,03 % (+/- 3dB 20 -20.000 Hz)
IHF dynamic power
Frequencyrespons
@ 8 Ohm: 50 W
@ 4 Ohm: 100 W
24-bit/192kHz via Optical Input
Supported bitsrate/sample-frequency
Gross dimensions W x H x D
220 x 63 x 252 mm
Net weight
4,85 kg (10,7 lb)
3 - 60.000Hz
INPUTS/CONNECTIONS
2x Optical Digital S/PDIF (Toshlink)
1x Analog stereo input (RCA)
1x Phono MM (Moving Magnet)
1x LAN Network connector
Signal/Noise ratio
Input impedance (40 watt bij 8 O hm)
Max. input signal level
>106 dB (A-Weight, Optical input, ref. 40 watt @ 8 Ohm) Line
in: 450mV Digital in: -5dB FS
>2.1V (ref. 0.1% THD)
5mV (ref.40watt 1Khz 8 Ohm @ max. volume)
Ingput sensitivity PHONO*
POWERCONSUMPTION
Standby-powerconsumption >0.5Watt, Network Standy
<3 watt
DIMENSIONS AND WEIGHT
Bluetooth receiver
WiFi WLAN 2.4 Ghz
NAD SHALL NOT BE HELD LIABLE FOR ANY TECHNICAL OR USER
INTERFACE DISCREPANCIES IN THIS MANUAL. THE AMP1 OWNER’S
MANUAL MAY BE SUBJECT TO CHANGE WITHOUT NOTICE. CHECK OUT
WWW.NADELECTRONICS.COM FOR THE LATEST VERSION OF THE AMP1
OWNER’S MANUAL.
