> SPECIFICATIONS
Over All Specifications
Line Level Input
Input impedance (R and C) 100 kΩ+ 320 pF
Input sensitivity 159 mV (ref. 500 mV out)
Maximum input signal >9 V
Signal/Noise ratio, A-weighted >108 dB (ref. 500 mV in 500 mV out,
volume set to unity gain)
>112 dB (ref. 2V out, Volume maximum)
Frequency response ± 0.1 dB (ref. 20 Hz - 20 kHz, Tone defeat ON)
± 0.5 dB (ref. 20 Hz - 20 kHz, Tone defeat OFF)
Frequency response
(subwoofer out) 100 Hz (ref. -3 dB)
Output
Output impedance
Pre out 75 Ω
Tape out Source Z + 1 kHz
Sub out 100 Ω
Headphones 10 Ω
Maximum voltage output
Pre out >10 V into 600 Ω
Tape out >10 V into 10 kΩ load
Sub out >7 V into 1 kΩ load
Headphones >7 V into 600 Ω
>2 V into 32 Ω
THD (CCIF IMD, DIM 100) >0.005 % dB (ref. 20 Hz – 20 kHz, 2 Vout)
Tone Controls
Treble ± 5 dB at 10 kHz (ref. 2V in 500 mV out)
Bass ± 5 dB at 100 Hz (ref. 2V in 500 mV out)
Power Consumption
Normal operation 21 W
Standby mode <0.8 W
Phono Input
Input impedance MC 40,100,600 Ω (R)
1 nF (C)
MM 47 kΩ (R)
220,300,400 pF (C)
Input sensitivity MC 0.15 mV (ref. 1 kHz 500 mV out)
MM 2.6 mV (ref. 1 kHz 500 mV out)
Input overload MC 0.8 mV/7 mV/65 mV (20 Hz/1 kHz/20 kHz)
MM 14 mV/140 mV/1.2 (20 Hz/1 kHz/20 kHz)
Gain MC in - Tape out 62.4 dB1 (ref. 1 kHz, 10 kΩ load)
MM in - Tape out 36.7 dB (ref. 1 kHz, 10 kΩ load)
THD (CCIF IMD, DIM 100) <0.009 % (ref. 20 Hz – 20 kHz, 5 Vrms Tape out)
Signal/Noise ratio,
IHF A-weighted MC >78 dB2 (ref. 0.5 mV)
MM >78 dB3 (ref. 0.5 mV)
RIAA response accuracy ± 0.5 dB (ref. 20 Hz – 50 Hz)
± 0.3 dB (ref. 50 Hz – 20 kHz)
Infrasonic filter 10 Hz (at -3 dB)
5 Hz (at -14 dB)
Physical Specifications
Dimensions (W x H x D) Net 435 x 80 x 286 mm
17 1/8” x 3” x 11 1/4”
Gross 435 x 99 x 315 mm
17 1/8” x 3 15/16” x 12 1/2”
Net weight 13.23 lb (6 kg)
Shipping
weight 17.1 lb (7.8 kg)
* Gross dimensions include volume knob / speaker ternimals / connectors / feet.
Note: Installers should allow a minimum clearance of 2- 4 inches for
wire managment.
