NAD C510 - Page 29

C939 A05-15242-00 Hign Voltage Cermatic Capacitor 1.5nF,400V(X1),250V(Y1),±20%,
C936 06-27111-00 Alu Electrolytic Capacitor HEN,270uF,16v,±20%
C938 06-12142-01 Alu Electrolytic Capacitor CD294,120uF,400V,±20%
c942 06-47021-02 Alu Electrolytic Capacitor CD263(X),47uF,25V,±20%,F2.5
C940 06-22051-04 Alu Electrolytic Capacitor CD263(X),22uF,50V,±20%,F2.5
C916, C917 06-10211-09 ALU Electrolytic CAP
EEUFM1C102B,1000uF,16V,±20%,105℃
FUSE
FUSE900 A20-12122-04 Fuse 5ET-013H, T1.25A 250V
ICS
IC903 03-00265-00 Power controller IC TOP265EG
TRANSFORMER
T900 A22-02625-01 Transformer Suzhou Hejia M51PQ26/25
INDUCTOR
L907, L908 22-23210-00 Common Mode Choke 10mH/2A,744823210
L900 08-02100-11 Inductance 10uH, GCP1014-100M
CONNECTOR
J900 13-23903-01 Connecter VH 3.96A-3A
J902 13-22507-00 Connector Socket XHB 2.5A-7A
HS900 61-023208-0 Self Tapping Screw BTB3×8
D906 78-013008-1 Insulated Cushion SQ9418, SPK-4
D906 85-157001-0 Transistor Washer TW-4
HS900
70-019005-1
Power Heatsink 6063 T5, BLACK
HS901 70-211002-0 Heatsink 6063 T5
HS901 85-211001-0 Parts Housing PTB, TC-21
HS901 61-023512-0 Machine Screw MB3×12
HS901 62-010302-0 Nut GB6170, M3
HS901 63-020309-0 Washer Spring GB/T 93 Φ3
HS901 63-010308-1 Plain Washer φ3,0.8mm
PCB-4:FPP BOARD
PART NO. DESCRIPTION
PCB INFO
A16-35103-22 FPP PCB VM1.1, FR-4, 1.6mm,2Layers, 1oz, TG130
A16-35130-22 FPP PCB ASSM VM1.1, FR-4, 1.6mm,2Layers, 1oz, TG130, 348×128mm
ICS
U501, U502 03-00717-01 Buffer NC7WZ17P6X
U504 03-02981-01 Regulator LP2981AIM5-5.0/NOPB
U505 03-00595-01 Shift Register SN74HC595D/74HC595D/MM74HC595M
U506 03-00165-01
8-Bit Serial or Parallel-Input/ Serial-Output
Shift Register
HC165
DIODE
D501, D502, D503, D504,
D512, D513, D515, D516
33-40352-01 Switch Diode 1SS352(TPH3,F),1SS355TE-17
D505 33-16809-10 Zener Diode 6.8V, 0.5W, LL34
D508 33-17509-03 Zener Diode BZT52C7V5-7-F,7.5V
D506 33-40021-11 small signal&high voltage switching diodes BAV21W
D506 or 33-40021-10 small signal&high voltage switching diodes BAV21W-V
D507, D509 33-44148-17 Switch Diode 1N4148
D500 33-50565-01 LED φ5,Blue. orange, BL-BJLB4274
S501, S500, S502 11-04101-05 TACT SW
J3002 13-22004-00 Connector PH2.0A-4A
TRANSISTOR
Q500, Q501 31-01015-03 Transistor A1015, SOT23
Q502, Q504, Q506 31-01815-03 Transistor C1815 SOT23
Q503, Q508 31-00114-05 Digital Transistor DTC114EKA
Q505 31-02301-01 P-CH MOSFET APM2301CAC, SOT23, Tape
Q507 31-03303-01 NPN EPITAXIAL TYPE 2SC3303
INDUCTOR
T500 22-00115-00 VFD TR EER11.5,I22CD22
L501 08-04331-06 Ferrite Bead SMD 742792037, 330ohm@100MHz, ±25%, 2A
L501 or08-04300-01 Ferrite Bead SMD BMB2A0300LN2
CAPACITOR
C3027, C3028 26-10321-00 Ceramic Chip Capacitor 10nK,16V,0603,X7R
C503, C506, C510, C523,
C524
26-10411-00 Ceramic Chip Capacitor 100nF,16V 0603, X7R
C525, C526 26-10511-00 Ceramic Chip Capacitor 1uF,16V 0603, X7R
C507, C508, C527, C528 26-22351-00 Ceramic Chip Capacitor 22nK,50V,0603,X7R
C509, C512 26-10611-11 Chip Capacitor 10uFK,10V,X5R,0805,C2012X5R1A106KT
C511, C513, C519, C520 26-10621-02 Ceramic Chip Capacitor 10uF, -20/+80%, 25V, Y5V
C514 06-22111-40 Chip Alu Electrolytic Capacitor 220uF,16V,±20%,VES221M1CTR-0607
C515, C516 26-10212-01 Ceramic Chip Capacitor 1nJ,100V,0805,NPO
C517,C521 26-10412-02 Ceramic Chip Capacitor 100nK,100V,1206,X7R
C518, C529 06-47051-12 Electrolytic Capacitor SMD
VZH series,47uF,±20%,50V,105℃,CAE6.3×
RESISTOR
R513, R514, R533, R534,
R537, R538, R528, R531,
R536
07-90101-00 Chip Resistor 100Ω,0603,1/10W,±5%,RC0603JR-07100RL
R516 07-90472-00 Chip Resistor 4.7KΩ,0603,1/10W,±5%,RC0603JR-074K7L
R512, R518 07-98201-00 Chip Resistor 8k2Ω 0603, 1/10W, ±1%
29
