NAD C510 - FPP Board Parts List; VFD and Encode Board Parts List

R501, R502, R508, R509,
R510, R532
07-90103-00 Chip Resistor 10KΩ,0603,1/10W,±5%,RC0603JR-0710KL
R506 07-90271-01 Chip Resistor 270Ω,0805,1/8W,±5%,RC0805JR-07270RL
R505 07-90471-01 Chip Resistor 470Ω,0805,1/8W,±5%,RC0805JR-07470RL
R526, R527 07-91201-01 Chip Resistor 1.2KΩ,0805,1/8W,±1%,RC0805FR-071K2L
R3043, R3046 07-91201-00 Chip Resistor 1.2KΩ,0603,1/8W,±1%,RC0805FR-071K2L
R520,R522, R523 07-90103-01 Chip Resistor 10KΩ,0805,1/8W,±5%,RC0805JR-0710KL
R524 07-90473-01 Chip Resistor 47KΩ,0805,1/8W,±5%,RC0805JR-0747KL
R517, R519 07-90000-02 Chip Resistor 0Ω 1206 1/4w
R515, R529, R530 07-93309-02 Chip Resistor 33Ω,1206,1/4W,±1%,RC1206FR-0733RL
R521 07-90470-03 Chip Resistor 47Ω,1210,1/2W,±5%,RC1210JR-0747RL
R525 07-90151-02 Chip Resistor 150Ω,1206,1/4W,±5%,RC1206JR-07150RL
R511 07-90331-02 Chip Resistor 330Ω,1206,1/4W,±5%,RC1206JR-07330RL
R507 07-90121-10 Chip Resistor NET 120Ω, ±5% R0603X4
R504, R535 07-90103-10 Chip Resistor NET 10KΩ×4, ±5% 0603×4
CONNECTOR
J500 13-21020-07 FFC Connector 1.0-9-20PB/ F10009Y-20-A013
14-65120-00 20Pin Cable 1.0mm pitch,20pin,L=160mm,coplanar
75-388001-0 VFD Cover Sheet PC Black UL94V-0 T=0.45mm
J501, J502 13-12507-08 Connector 2.54mm,7Pin,CNT-M254-1*7-GS-7/3-N
J505 13-12504-21 Header 2.54pitch, 4Pin, CNT-M254-1*4-GS-7/3-N
61-023512-0 Machine Screw MB3×12
62-010302-1 NUT M3
85-332002-0 Round Spacer 3.5-4.5
PCB-5:VFD BOARD
PART NO. DESCRIPTION
PCB INFO
A16-35106-21 VFD PCB
VM1.0, FR-4, 1.6mm,2Laers, 1oz, TG130, 172.8×
48.5mm
A16-35140-21 VFD Board+ENCODE Board
VM1.0, FR-4, 1.6mm, 2Laers, 1oz, TG130, 203.8×
58.5mm
INDUCTOR
L500 08-04331-06 Ferrite Bead SMD 742792037, 330ohm@100MHz, ±25%, 2A
L500 or08-04300-01 Ferrite Bead SMD BMB2A0300LN2
RESISTOR
R500 07-90100-01 Chip Resistor 10Ω,0805,1/8W,±5%,RC0805JR-0710RL
R503 07-90101-00 Chip Resistor 100Ω,0603,1/10W,±5%,RC0603JR-07100RL
CAPACITOR
C505 26-39051-00 Ceramic Chip Capacitor 39pJ,50V,0603,NPO
C500, C502 26-10411-01 Ceramic Chip Capacitor 100nK,16V,0805,X7R
C504 26-10411-00 Ceramic Chip Capacitor 100nF,16V 0603, X7R
C501 26-22660-11 Ceramic Chip Capacitor 22uF, 6.3V, X5R, 0805
IC
U500 03-34838-00 IR Receiver TSOP34838
CONNECTOR
U503 23-01611-0
0
VFD DISPLAY CIG33-1611N
B75-211001-
0
VFD Bracket
A
BS 765B,Black
67-017004-
0
IR Bracket xxxxxx
x
66-017004-
0
IR Bracket TIN Plate t=0.3mm
PCB-6:ENCODE BOARD
PART NO. DESCRIPTION
PCB INFO
A16-35104-21 ENCODE PCB VM1.0, FR-4, 1.6mm,2 Layers, 1oz,, TG130, 31×45mm
A16-35140-21 VFD Board+ENCODE Board
VM1.0, FR-4, 1.6mm, 2 Layers, 1oz,, TG130,203.8×
58.5mm
RESISTOR
R3044, R3045 07-90103-00 Chip Resistor 10KΩ,0603,1/10W,±5%
C3029 26-10611-01 Ceramic Chip Capacitor 10uF,0805,10V,C0805C106M8PACTU
C3030, C3031 26-10411-00 Ceramic Chip Capacitor 100nF,16V 0603, X7R,±10%
CONNECTOR
Connect FPP Board and
ENCODE Board
14-23304-00 Connector Wire UL1007#24AWG,L=170mm
S3000 28-15304-00 Encoder EC11E1530401
Mechanical Parts
AC inlet to switch A14-04201-00 Cable UL1672#18AWG ,L=80mm
AC inlet to chassis A14-33201-00 1PIN CBALE ,L=100mm
14-65107-00 CABLE UL1569#22AWG,L=80mm
A11-01101-03 ROCKER SWITCH RF1003, TV-5 (10A 250VAC)
AC INLET A20-12102-00 FUSE 0618001MXP, T1AL/250V
A17-07103-12 AC Inlet RF-2004
AC INNET TO SMPS Board 14-65102-00 CABLE UL1672#18AWG,L=250mm
AC Cord
JA15-15121-00 AC Cord LP-31 & SJT 16/3C BLK L=1800 & LS-13
or NA15-13125-00 AC Cord 3UTJ2 & SJT 16AWG*3 L=1800 & 3GTJA
or A15-16251-00 AC Cord PS204 & SJT 16AWG*3 L=2000 & V1625BS
30
