JA15-16250-00 AC Cord LP-34 & H05VV-F 3×1.00mm2 6' BLK & LS-60
or NA15-16250-07 AC Cord 3VTJ1 & H05VV-F 3×1.00mm2 L=1800 BLK & 3VTJA
or A15-10230-2
0
A
C Cord T973-C
REMOTE CONTROL
30-13510-00 Remote Control DR-1,XHY558F43-5
30-22100-10 Batteries
METAL PARTS
67-388001-0 Chassis
SECC-N5 T=1.0mm
65-388001-0 Chassis
SECC-N5 T=1.0mm
67-388003-0 Subfascia
SECC-N5 T=1.0mm
65-388003-0 Subfascia
SECC-N5 T=1.0mm
67-388002-0B Rear Panel SECC-N5,T=1.0mm
80-388002-0 Rear Panel SECC-N5,T=1.0mm
65-388002-0 Rear Pane SECC-N5,T=1.0mm
PLASTIC PARTS
PMMA 76-388001-0 VFD Lens PMMA
87-124001-0 Foot ASSY
75-124001-0 Foot ABS765B,Black
78-001002-1 Foot Pad MX-48HF,HV:90°±2 °, OD:25.5mm,ID14.1mm,T=3mm
FASTENERS
HDMI Socket(3) 61-023506-0 machine Screw MB3×6
Main PCB（3），Power PCB
（4）
61-373506-0 Machine Screw M3×6
Rear Panel Socket10) 61-023208-0 Self Taping Screw BTB3×8
Lower panel(4) 61-023108-0 Self Taping Screws STB3×8
Foot(4), Rear
Panel(7),Subfascia(4)，,potenti
ometer Board(2)
61-023106-0 Self Taping Screw STB3×6
Subfascia(4) 61-063105-0 Self Taping Screw STF3×5
LR End cap (4),FPP Board(8) 61-023206-0 self taping screw BTB3×6
ground connection(1) 62-010402-0 Nut GB6170-86, M4
63-020411-0 Spring Washer GB93-87 φ4
63-010408-0 Plain Washer GB97.1-85 φ4
84-005001-0 Cable Tie YJ-100
ACCESSORIES
panel(1) 79-134001-0 CR Foam CR UL94V-0
panel(1) 79-124003-0 CR Foam C CR
panel(3) 79-134002-0 Rubber Pad
UL9
4V-1, 20×5.8×7.5
86-009003-0 3mm Rubber Pad 10×10×3mm
86-018001-0 Non-woven Cloth 24x14x0.5mm
PACKING LIST
88-388001-0A Carton Box 544mm×377mm×162mm
89-223001-1 EPE End Cap EPE((0.028g/cm3)
89-223002-1 EPE End Cap EPE(0.028g/cm3)
90-001001-0 Polybag 630X440mm
90-223001-0 Polybag HDPE ,550X250mm
30-43510-00 Quick Setup Guide
157g,
420X297mm
90-001002-0 Polybag 370*220mm HDPE
90-001013-0 AC Cord Polybag 105X280mm
90-009002-1 Non-woven Cloth H=80 W=100 L=435
94-388001-0 Series No Label 53×10mm
86-000053-0 Copperplate Lable 53×10mm
94-388002-0 Version Label 115×85mm
94-388003-0 Version Label 115×85mm
30-51500-01 Guarantee Card 210X148mm, 250g
Assembly
67-223003-1 Top Cover SECC-N5, T=1.2mm,PPG:PCSC90103S#5
