NAD CI 940 - Page 22

MISC
HS101, HS201, HS301, HS401 78-040001-0 Heatsink Cushion HS4-860-B009V1-P007
FB501 79-132001-0 CR PAD CR Black, 26*26*12.5mm
METAL PARTS
G8G1 32-28042-00 Ground Solder Tap GND-8
HS101, HS201, HS301, HS401 70-460005-0 Heatsink4
AL6063,T=3mm,black
oxide,H=35mm
BUS801 69-010001-0 BUSBAR HS4-T972-B009V1-M015
FASTENERS
R290Heatsink(C) 61-023508-0 Machine Screw MB3×8,plated black zinc
01-94000-00 ASSY HEATSINK
70-460001-3 Main Heatsink 6063 T5, black oxide
66-001009-0 CLAMPER HS4-C320-B009V1-M012
66-018005-0 Tem.Sw Clamp
65Mn HRC48-52 HS4-
C372B009V1M014
61-354516-0
Hexagon Socket Head
Screw
M4×16,plated black zinc
CLAMPER(2X2) 63-010408-0 Plain Washer GB97.1-85 φ4, plated blue zinc
CLAMPER(2X2) 63-020411-0 Spring Washer GB93-87 φ4, plated blue zinc
Fixed thermistor 61-023508-0 Machine Screw MB3×8,plated black zinc
Tem.Sw Clamp 61-023510-0 Machine Screw MB3×10,plated black zinc
78-001004-0 Heat Conductive Pad SFAT482
Q116, Q216, Q316, Q416 31-00669-01 Transistor 2SD669A-C, TO126
Q111, Q211, Q311, Q411 31-02121-00 Transistor 2SA2121-O
Q112, Q212, Q312, Q412 31-05949-00 Transistor 2SC5949-O
CB801, CB802 A07-70022-09 THERMAL CIRCUIT BRAKE ST-22 90C L TYPE
R2000, R2008 07-70103-08 NTC
103AT-4,10KΩ 1% shape 1，
L=75mm,103AT-4-80025
To the mainboard R2000 R2008 fixed
on the Main Heat sink
A16-94007-21 NTC PCB
VM1.0 FR-4,1.6mm,2Layers,1Oz
, TG130, 25×6mm
3XPower key BOARD;3XDISPLAY
BOARD，6xNTC board
A16-94020-21
DISPLAY+Power key
BOARD +NTC Board PCB
ASSY
VM1.0 FR-4,1.6mm,2Layers,1Oz
, TG130,TG130, 153×160mm
PCB-2:DISPLAY BOARD
PART NO. DESCRIPTION
PCB INFO
01-94002-00 CI940 DISPLAY BOARD
02-94002-00 CI940 DISPLAY BOARD SMT
A16-94002-21
DISPLAY BOARD PCB
ASSY
VM1.0 FR-4,1.6mm,2Layers,1Oz,
TG130, 106×42mm
3XPower key BOARD;3XDISPLAY
BOARD，6xNTC board
A16-94020-21
DISPLAY+Power key
BOARD +NTC Board PCB
ASSY
VM1.0 FR-4,1.6mm,2Layers,1Oz
, TG130, 153×160mm
DIODE
D901 33-14709-10 Zener Diode 4V7,1/2W, LL34
Q905, Q906, Q907, Q908, Q909, Q910,
Q911
31-00114-01 Transistor DTA114EKA
D903, D904 33-50326-04 LED
φ3,red blue,BL-BUBB5201G-YJ-
T05
24
