NAD CI 940 - Page 23

RESISTOR
R901, R902, R903, R904, R907 07-90103-01 Chip Resistor
10KΩ,0805,1/8W,±5%,RC0805JR-
0710KL
R905, R906 07-90472-01 Chip Resistor
4.7KΩ,0805,1/8W,±
5%,RC0805JR-074K7L
R908, R912, R913 07-90102-01 Chip Resistor
1KΩ,0805,1/8W,±5%,RC0805JR-
071KL
R909, R910, R911, R914,R916 07-95100-01 Chip Resistor
510Ω,0805,1/8W,±1%,RC0805FR-
07510RL
R915, R917 07-95101-01 Chip Resistor
5.1KΩ,0805,1/8W,±
1%,RC0805FR-075K1L
R918 07-94701-00 Chip Resistor
4.7KΩ,0603,1/10W,±
1%,RC0603FR-074K7L
CAPACTIOR
C902 C909 26-10451-21 Ceramic Chip Capacitor
100nJ,50V,0805,X7R,CC0805JRX
7R9BB104
C903, C904 26-22051-01 Ceramic Chip Capacitor 22PJ,50V,0805,NPO
CRYSTAL
X901 04-11102-01 Crystal SMD HLX-M-T-11.0592M-20-TR
TRANSISTOR
Q901, Q902 31-01015-03 Transistor A1015, SOT23
Q903, Q904 31-01815-03 Transistor C1815 SOT23
IC
IC901 03-00162-01 MCU STC12C5A16S2-35I-LQFP44
FERRITE BEAD
L901 08-04331-06 Ferrite Bead SMD
742792037, 330ohm@100MHz,
±25%, 2A
CAPACTIOR
C905, C906,C907 06-10051-02 Alu Electrolytic Capacitor CD263(X),10uF,50V,±20%,105℃
C901 06-10211-05 ALU Electrolytic Capacitor
CD263X,1000uF,10V,±20%,105
℃,F5.0
C908 25-10461-07
Metallized Polyester Film
Capacitor
CL23B-63V-104JR,
C241J104J20A201
CONNECTOR
P901A 14-94011-00 Connector UL2468#24AWG*11P, L=160mm
J901 13-12504-28 Connector
2.54mm pitch,4pin,CNT-M254-
1*4-GS-5/3-N
JA20 13-22505-00 Connector XHB 2.5A-5A/TJC3-5A
PCB-3:INPUT BOARD
PART NO. DESCRIPTION
PCB INFO
01-94003-00 Input Board
02-94003-00 Input Board SMT
A16-94003-22 Input Board PCB
VM1.1, FR-4,1.6mm,2Layers,1Oz,
,TG130
2xInput board A16-94030-22 Input Board PCB ASSY
2->1,VM1.1 FR-
4,1.6mm,2Layers,1Oz, TG130,
132×128mm
DIODE
DA05, DA06, DA07 33-40352-01 Diodes 1SS352
DA01, DA02 33-40099-04 Switch Diode BAV99
D2002, D2005 33-40021-11 Switch Diode BAV21W,SOD123
DA03, DA04 33-12009-10 Zener Diode SMD 2V, 1/2W , LL34
25
