RESISTOR
RA06,RA07,RA29 07-91001-00 Chip Resistor 1KΩ,0603,1/10W,±1%
RA13, RA20, RA21 07-92201-00 Chip Resistor 2.2KΩ,0603,1/10W,±1%
RA11,RA15,RA16,RA18 07-91002-00 Chip Resistor 10KΩ,0603,1/10W,±1%
RA10 07-92202-00 Chip Resistor 22KΩ,0603,1/10W,±1%
RA05,RA08,RA14,RA17,RA19 07-91003-00 Chip Resistor 100KΩ,0603,1/10W,±1%
RA01,RA02,RA03,RA04,RA09 07-92203-00 Chip Resistor 220KΩ,0603,1/10W,±1%
RA12 07-91004-00 Chip Resistor 1MΩ,0603,1/10W,±1%
LA02,LA03 07-90000-01 Chip Resistor
0Ω,0805,1/8W,±5%,RC0805JR-
0722RL
R2002,R2009 07-92202-01 Chip Resistor
22KΩ,0805,1/8W,±
1%,RC0805FR-0722KL
R2003,R2010 07-93002-01 Chip Resistor
30KΩ,0805,1/8W,±
1%,RC0805FR-0730KL
R2004,R2011 07-98201-01 Chip Resistor
8.2KΩ,0805,1/8W,±
1%,RC0805FR-078K2L
R2005,R2012 07-91202-01 Chip Resistor
12KΩ,0805,1/8W,±
1%,RC0805FR-0712KL
R2007,R2014 07-90104-01 Chip Resistor
100KΩ,0805,1/8W,±
5%,RC0805JR-07100KL
R2013,R2015 07-92200-01 Chip Resistor
220Ω,0805,1/8W,±1%,RC0805FR-
07220RL
CAPACTIOR
CA07 26-47951-00 Ceramic Chip Capacitor 4.7pJ,50V,0603,NPO
CA09 26-22511-20 Ceramic Chip Capacitor 2.2uK,16V,0603,X7R
CA01,CA02,CA03,CA04,CA06,CA08,C
A12
26-10451-10 Ceramic Chip Capacitor 100nK,50V,0603,X7R
CA13, CA14 26-10511-20 Ceramic Chip Capacitor
1uK,16V,0603,X7R,C1608X7R1C1
05K
C2001,C2004 26-10351-01 Electrolytic Capacitor SMD 10nK,50V,0805,X7R
CA18 26-10451-11 Ceramic Chip Capacitor
100nK,50V,0805,X7R,C2012X7R1
H104KT
CA05,CA11 26-10611-11 Ceramic Chip Capacitor
10uFK,10V,X5R,0805,C2012X5R1
A106KT
CA17 06-10011-20
Chip Alu Electrolytic
Capacitor
10uF,16V,±20%,105
℃,VZH100M1C0406-TR0
CA10 06-10111-33
Alu Electrolytic Capacitor
SMD
100uF,10V,±20%,85℃,VE-
101M1A0605-TR0
C2000 06-10121-02 Alu Electrolytic Capacitor
CD263(X),100uF,25V,±20%,105
℃,F5.0
C2002, C2003 06-22121-03 Alu Electrolytic Capacitor CD263(X),220uF,25V,±20%,F5.0
TRANSISTOR
QA06 31-00856-03 Transistor BC856BW SOT323
QA04 31-00846-02 Transistor BC846BW SOT323
QA01, QA02, QA03, QA05 31-01815-03 Transistor C1815 SOT23
Q3,Q4 31-02222-02 Transistor PZT2222AT1G, NPN
Q3,Q4 or 31-05516-01
NPN Medium Power
Transistors
BCP55-16
Q3,Q4 or 31-00493-00 Transistor FZT493
IC
IC01,U2000 03-00082-01 Dual OPAMP TL082BCDR
RELAY
RL101, RL102 12-02202-17 Signal Relay HFD4/5-SR
HEATS INK
Q3, Q4 J70-287007-0 Heatsink 7106D/TRG
INDUCTOR
LA01 08-02100-01 Inductor 10uH LGK0305-200N, Pitch=5mm
CONNECTOR
