NAD CI 940 - Page 25

JA01, JA02 17-01004-00 4RCA AV4-8.4-13, 4RCA
J2010 13-22504-05 Connector Socket XHB 2 .5A-4AW
J2003, J2004 13-22502-00 Connector Socket XHB 2.5A-2A
PA01A 13-22511-02 HOUSING XHB-11AW
67-114001-0 PCB Terminal HS40-360.1-B009V1-M002
PCB-4:POWER KEY BOARD
PART NO. DESCRIPTION
PCB INFO
01-94004-00 POWER KEY BOARD
A16-94004-21 POWER KEY PCB
VM1.0 FR-4,1.6mm,2Layers,1Oz,
TG130, 37×50mm
3XPower key BOARD;3XDISPLAY
BOARD，6xNTC board
A16-94020-21
DISPLAY+Power key
BOARD +NTC Board PCB
ASSY
VM1.0 FR-4,1.6mm,2Layers,1Oz,
TG130, 153×160mm
SWITCH
S901 11-04101-05 TACT SWITCH IT-1102A-1160
JA21 13-22505-00 Connector XHB 2.5A-5A/TJC3-5A
DIODE
D902 33-50565-12 LED (three color) BL-BB3JCUB2C4V-1-10F
PCB-5:PSU BOARD
PART NO. DESCRIPTION
PCB INFO
01-94005-00 PSU BOARD
02-94005-01 PSU BOARD SMT
A16-94005-22 PSU BOARD PCB
VM2.0,FR-4,1.6mm
,2Layers,1Oz,TG130, 115×197mm
DIODE
D907, D908, D909, D910, D911, D917 33-20316-01 High speed Diode BAS316
D907, D908, D909, D910, D911, D917 or N33-44448-01 High speed Diode IN4448HWS-7-F
D901, D902, D903, D904, D905, D906,
D913
33-40054-02 Schottky Rectifier Diode BAT54J
T902, T903, T904, T905, T906, T907 33-40056-00 High-speed double diode BAW56W SOT323
T902, T903, T904, T905, T906, T907 or 33-40056-01 High-speed double diode BAW56W-7-F
D922 33-20007-00 Rectifier Diode M7A, 1A 1000V
D914, D916 33-20220-01 Ultrafast Power Rectifier MURA220T3G
D919 33-44148-17 Schottky Rectifier Diode 1N4148
D920 33-20120-01 Schottky Rectifier Diode MURS120/MURS120T3G
BD901 33-30062-00 BRIDGE RECTIFIER B6S, 0.8A 600V
D923 33-11800-30 Zener Diode 18V, 3W, ±5%, SMA
D921 33-23100-00 Schottky Rectifier Diode MBRS3100T
BR901 33-31562-01 Rectifier Bridge GBU1506C
D918 33-24006-00 Rectifier Diode UF4006
D912 33-26200-00 Transient Suppressor P6KE-200A
TRANSISTOR
Q902, Q903, Q906, Q907, Q908, Q909,
Q910, Q911
31-00807-40 Transistors BC807-40W PNP
Q904, Q905 31-00817-40 Transistors BC817-40W PNP
27
