NAD CI 940 - Page 30

R965, R972 07-91001-00 Chip Resistor
1KΩ,0603,1/10W,±
1%,RC0603FR-071KL
R966 07-92701-00 Chip Resistor
2.7KΩ,0603,1/10W,±
1%,RC0603FR-072K7L
R957, R958, R963, R967, R971 07-91002-00 Chip Resistor
10KΩ,0603,1/10W,±
1%,RC0603FR-0710KL
R970 07-94702-00 Chip Resistor
47KΩ,0603,1/10W,±
1%,RC0603FR-0747KL
R952, R953, R959, R961, R962, R968,
R969
07-91003-00 Chip resistor
100KΩ,0603,1/10W,±
1%,RC0603FR-07100KL
R955, R960, R964 07-91803-00 Chip resistor
180KΩ,0603,1/10W,±
1%,RC0603FR-07180KL
R974 07-92203-00 Chip resistor
220KΩ,0603,1/10W,±
1%,RC0603FR-07220KL
R956 R973 07-94703-00 Chip resistor
470KΩ,0603,1/10W,±
1%,RC0603FR-07470KL
R951 07-99093-00 Chip Resistor
909KΩ,0603,1/10W,±
1%,RC0603FR-07909KL
CAPACTIOR
C955 26-10251-00 Ceramic Chip Capacitor 1nK,50V,0603,X7R
C950, C953, C954 26-10421-20 Ceramic Chip Capacitor
100nK,25V,0603,X7R,GRM188R7
1E104KA01D
C951, C952 26-22421-00 Ceramic Chip Capacitor
220nK,25V,0603,X7R,C1608X7R1
E224KT
C957 26-47511-01 Chip Capacitor
4.7uK,16V,X5R,0805,C2012X5R1
C475K
C956 26-22611-02 Chip Capacitor
22uM,10V,1206,X5R,C3216X5R1
A226MT
CONNECTOR
J901 13-12009-01 Connector CNT-M200-1*9-GD-3.4/2.4/0
PCB-7:DCDC BOARD
PART NO. DESCRIPTION
PCB INFO
01-94006-00 DCDC BOARD
02-94006-00 DCDC BOARD SMT
A16-94006-21 DCDC PCB
VM1.0,FR-4,1.6mm ,2Layers,2Oz,
TG130
A16-94060-21 DCDC PCB ASSM
20->1, VM1.0,FR-4,1.6mm
,2Layers,2Oz, TG130 ,110×
134mm
IC
U801 03-54140-01 Power controller IC TPS54140ADGQR,MSOP-10
DIODE
D803 33-20340-02 SCHOTTKY DIODE B340A-13-F 40V 3A
INDUCTOR
L804 08-04100-05 Power Inductor
10uH,3A,GPSR0730-100M
7.2*6.6mm
RESISTOR
R826 07-93323-00 Chip Resistor
332KΩ,0603,1/10W,±
1%,RC0603FR-07332KL
R827 07-96202-00 Chip Resistor
62KΩ,0603,1/10W,±
1%,RC0603FR-0762KL
R831 07-98062-00 Chip Resistor
80.6KΩ,0603,1/10W,±
1%,RC0603FR-0780K6L
R828 07-99092-00 Chip Resistor
90.9KΩ,0603,1/10W,±1%
RC0603FR-0790K9L
R834 07-95232-00 Chip Resistor
52.3KΩ,0603,1/10W,±
1%,RC0603FR-0752K3L
32
