R868 07-91002-00 Chip Resistor
10KΩ,0603,1/10W,±
1%,RC0603FR-0710KL
R830 07-91008-00 Chip resistor
1Ω,0603,1/10W,±1%,RC0603FR-
071RL
CAPACITOR
C812 26-10451-11 Ceramic Chip Capacitor
100nK,50V,0805,X7R,C2012X7R1
H104KT
C813 26-12351-10 Ceramic Chip Capacitor
12nK,0603,50V,X7R,C1608X7R1H
123KT000N
C810, C811 26-22551-02 Ceramic Chip Capacitor
2.2uK,50V,1206,X7R,CC1206KKX
7R9BB225
C816 26-56951-10 Ceramic Chip Capacitor
5.6pF,50V,0603,NPO,±
0.25pF,C1608C0G1H5R6CT
C817 26-27251-00 Ceramic Chip Capacitor 2n7K,50V,0603,X7R
C819,C821 26-10711-02 Ceramic Chip Capacitor
100uF, 10V, ±20%,X5R 1206,
C3216X5R1A107M
C814 26-10421-10 Cermatic Chip Capacitor 100nK,25V 0603,X7R
CONNECTER
J801, J888 13-12002-06 Header CNT-M200-1*2-GD-3.4/2.4/0
WHOLE UNIT ASM
SWITCH
SW600 A11-01101-03 ROCKER SWITCH
RF-1003-BBG8A2L1T, 10A 250V,
TV-5
AC INLET
U600 A17-07002-07 AC INLET SS-7BA-4.0
U600 or A17-07002-00 AC INLET 3516-T1C02
CABLE
Connect Main Board P804B And Audio
Input Board PA01B
14-94011-01 WIRE UL1007#22AWG,L=120mm
Connect Main Board J2005 And Audio
Input Board J2010
14-94004-00 WIRE UL2468#26AWG*4P,L=120mm
PSU Board J902 TO MAIN Board
P803B
14-94004-11 Cable UL1569#16AWG,L=250mm
Connect DISPLAY Board JA20 and
Switch Board JA21
14-41255-00 WIRE UL2468 26AWG,L=150mm
AC INLET to Switch A14-37501-10 WIRE UL1672#16AWG,Red,L=100mm
Switch to Fuse holder 14-47001-12 WIRE UL1672,18AWG,L=150mm
14-24502-01 WIRE
UL1672#18AWG
,L=300mm(blue)/L=220mm(red)
A20-12502-00 FUSE 0618005MXP, T5AL/250V
JA20-20000-10 Fuse Holder FPG1 3101.0010
A15-10125-11 AC Cord
DTI-2P-02( polarity)+SVT 105C
18AWG/2C+DTII-2P-
04,L=1800mm,Black
or JA15-10125-01 AC Cord
LP-13W &,SVT 18AWG×2,Black
6'& LP-16
or A15-10125-00 AC Cord ME302P,SJT 18AWG×2,VAC17S
A15-16250-17 AC Cord
SP-026+IS-14A H05VV-F 2*0.75
凹 C-12(BLACK) L=1.8M
(Y6A6B20161218000)
or JA15-10250-20 AC Cord
PE-224 & H05VV-F, 2×
0.75mm2,2C Black 6'& LS-20
or A15-10250-00 AC Cord
M3204,H05VV-F 2×
0.75mm,VAC17S
FAN
33
