A35-26025-01 Fan FD126025-SM1,L=11cm
METAL PARTS
70-460004-0B front panel AL6063 T5
67-460001-1 subfascia SECC T=1.2mm
65-460001-1 subfascia SECC T=1.2mm
66-420003-0 converter block SECC T=1.5mm
70-420007-1 Moutain Bar 2 AL 6063 T5
70-420008-1 Moutain Bar 1 AL 6063 T5
70-420012-1 Handle AL 6063 T5
67-420007-0 fan guard G06B4-4HA-R
67-420005-1 Mesh SPCC T=0.5mm
66-460001-1 chassis SECC T=1mm
66-460002-0 repair window SECC T=1mm
M67-460002-2C rear panel SECC T=1mm,
80-460002-2 rear panel SECC T=1mm
65-460002-2 rear panel SECC T=1mm
67-460003-1 top cover SECC T=1mm
65-460003-1 top cover SECC T=1mm
MECHANISM
PARTS
78-001002-1 Foot pad
VHMC-30U, HV=:90°±2
°,OD=25.5mm,ID=14.1mm,T=3m
m
75-124001-0 Foot ABS765B
74-123003-1 C725BEE 2p Input Buttons
ABS 765B
77-124004-0
C375BEE Power Button
Bezel
UL94V-0
76-008001-0 LED lens PMMA
86-046001-0 LED Lens Gum 3m Dobble side adhensive
78-460001-0 Insulated Cushion GK17, T=0.5mm
EVA
79-420002-0 EVA1 34*10*3mm
79-420003-1 EVA2 65*18*2mm
79-460001-0 Indicator light EVA
79-420004-0 EVA3 420*8*0.5mm
79-420005-1 EVA4 398*8*1mm
79-272004-0 SPONGE L110*W30*T5mm
FASTENERS
Fixed Bottom Board PCB(2)，Power
Borad(4)
61-023508-2 Machine Screw
MB3x8，plated nickel
Fixed Moutain 1(2),Moutain
2(2),Handle(4)
61-064510-0 Machine Screw MF4x10, plated black zinc
Fixed Bottom Board，front panel and
subfascia(4)，subfascia and converter
block(4),RCA(2)
61-023208-0 Self Tapping Screw BTB3×8,plated black zinc
Fixed fan and fan guard 61-083532-6 Machine Screw MPW3x32
Fixed fan(8),Fixed subfascia Insulated
Cushion(4)
62-010302-1 Nut M3,plated blue zinc
Fixed switch PCB(3),LED PCB(4),Fixed
subfascia Insulated Cushion
61-023506-0 Machine Screw MB3×6,plated black zinc
Install top cover 61-084208-0 Self Tapping Screw BTPW4x8, plated black zinc
Main Heat sink(8) 61-023512-0 Machine Screw MB3x12,plated black zinc
