All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive lter and AES 17 active lter.
AMPLIFIER SECTION
LINE INPUT, SPEAKER OUT
Continuous output power into 8 ohms and 4 ohms 100W (ref. 20 Hz-20 kHz at rated THD, both channels driven)
THD (20 Hz – 20 kHz) <0.03 % (250 mW to 100 W, 8 ohms and 4 ohms)
Signal-to-Noise Ratio >90 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)
Clipping power >130 W (at 1 kHz 8 ohms 0.1 % THD)
>230 W (at 1 kHz 4 ohms 0.1 % THD)
IHF dynamic power 8 ohms: 160 W
4 ohms: 300 W
Damping factor >190 (ref. 8 ohms, 20Hz to 6.5kHz)
Frequency response ±0.6 dB (20 Hz - 20 kHz)
Tone controls Treble: ±6.0 dB at 20 kHz
Bass: ±6.0dB at 60 Hz
Channel separation >75 dB (1 kHz)
>70 dB (10 kHz)
Input sensitivity (for 100 W in 8 ohms) Line In: 1.0 V
Digital In: -6.2 %FS
Standby power 0.5W
DAC SECTION
Supported audio le formats MP3, AAC, WMA, OGG, WMA-L, ALAC, OPUS
Hi-Resolution audio formats MQA, DSD, FLAC, WAV, AIFF
Sampling rate up to 32 bit/192 kHz PCM
Bit depths 16 – 24
BLUOS SECTION
Supported operating systems Plays music from network shares on the following desktop operating systems: Microsoft
Windows XP, 2000, Vista, 7, 8 to current Windows Operating Systems and Mac OS X versions
User interface mobile operating system BluOS - Free Android and iOS App available online at Google Play and Apple App store
Supported cloud services* Spotify, Amazon Music, TIDAL, Deezer, Qobuz, HDTracks, HighResAudio, Mure, JUKE,
Napster, Slacker Radio, KKBox, Bugs
Free internet radio* TuneIn Radio, iHeartRadio, Calm Radio, Radio Paradise
Bluetooth quality Bluetooth aptX HD built-in
Bluetooth connectivity Two-Way (Receive and Headphone modes)
Network connectivity Gigabit Ethernet RJ45
802.11 b/g/n WiFi
DIMENSION AND WEIGHT
Gross dimensions (W x H x D)** 215 x 100 x 260 mm
8 ½ x 3 ⁄ x 10 ¼ inches
Shipping weight 5 kg (11 lbs)
* - Supported cloud services and free internet radio are subject to change without notice.
** - Gross dimension includes feet and extended rear panel terminals
Specifications are subject to change without notice. Check out www.NADelectronics.com for updated documentation or latest information about M10.
REFERENCE
SPECIFICATIONS
