NAD M25 - Page 3

Continuous Power, 20Hz-20kHz, all channels
driven simultaneously at 4/8 ohms
Rated Distortion (THD 20Hz-20kHz)
Clipping Power (0.1% THD)
IHF dynamic headroom at 4 ohms
IHF dynamic power at 8 ohms
IHF dynamic power at 4 ohms
IHF dynamic power at 2 ohms
Damping Factor
Input Impedance
Input Sensitivity
Voltage Gain
Frequency Response
Signal/Noise Ratio
Dimensions (W x H x D)
Net Weight
Shipping Weight
>160 W (22.0 dBW)
0.03%
>180 W
3.9dBW
>220 W (23.4 dBW)
>385 W (25.9 dBW)
>485 W (26.9 dBW)
ref. 8 ohms, 50Hz >180
1 Mohms;C = 180 pF
1250mV+/-50mV
29.0dB
20 Hz – 20 kHz ±0.2 dB
- 3dB at 3 Hz/70 kHz
>96 dB ref. 1 W
>118 dB ref. 160W
17 x 7 7/8 x 18 3/8”
435 x 200 x 465.6mm
96.3 lbs (43.7 kg)
112.3 lbs (51.0 kg)
Preliminary Specifications
