NAD T 741 - Electrical Parts List; AC3 Board Parts; Capacitors

52
AC3 BOARD
1000 PCB-N0A00C-AC3 AC3 ASSEMBLY
MISCELLANEOUS
2702 2954-3008-0000 TAPPING 3X8MM B-TITE
2703 4151-9931-0 INSULATION BUSHING
2704 2954-2606-0000 SCREWS BT 2.6X6
CAPACITORS
C101 150F-104K-J-BD CC 50V 0.1μF 10% 0805
C102 150E-104M-J-BD CC 25V 0.1μF 20% 0805
C103 150F-104K-J-BD CC 50V 0.1μF 10% 0805
C104 157C-108M-5-S5 CE 10V 1000μF 20% RL
C105 150F-103K-J-BD CC 50V 0.01μF 10% 0805
C106 150F-104K-J-BD CC 50V 0.1μF 10% 0805
C107 157D-228M-5-W@T CE 16V 2200μF 20% RL
C108 150F-104K-J-BD CC 50V 0.1μF 10% 0805
C1101 157D-475M-5-EI CE 16V 4.7μF 20% RL 3x5
C1102 15FF-224Z-J-BD CC 50V 0.22μF +80/-20%
C1104 157D-475M-5-EI CE 16V 4.7μF 20% RL 3x5
C1105 15FF-224Z-J-BD CC 50V 0.22μF +80/-20%
C1106, C1107 157D-226M-5-GM CE 16V 22μF 20% RL 4X7
C1110 150F-151K-J-BD CC 50V 150pF 10% 0805 1.
C1111 150D-224K-J-BD CC 16V 0.22μF 10% 0805
C1112-C1114 150F-104K-J-BD CC 50V 0.1μF 10% 0805
C1115 157D-106M-5-GM CE 16V 10μF 20% RL 4x7
C1116 157E-105M-5-EI CE 25V 1μF 20% RL 3x5
C1117 157D-475M-5-EI CE 16V 4.7μF 20% RL 3x5
C1118 157D-227M-5-KW CE 16V 220μF 20% RL 6x12
C1119 157D-475M-5-EI CE 16V 4.7μF 20% RL 3x5
C112 150F-151K-J-BD CC 50V 150pF 10% 0805 1.
C1120, C1121 157D-475M-5-EI CE 16V 4.7μF 20% RL 3x5
C1122, C1123 150F-104K-J-BD CC 50V 0.1μF 10% 0805
C113 150F-562K-J-BD CC 50V 5600pF 10% 0805
C1131, C1132 150F-104K-J-BD CC 50V 0.1μF 10% 0805
C1133 150F-100J-J-BD CC 50V 10pF 5% 0805 1.2x
C1134 150F-104K-J-BD CC 50V 0.1μF 10% 0805
C1135 150F-100J-J-BD CC 50V 10pF 5% 0805 1.2x
C1136, C1137 150F-104K-J-BD CC 50V 0.1μF 10% 0805
C1138 150D-224K-J-BD CC 16V 0.22μF 10% 0805
C114, C115 157D-226M-5-GM CE 16V 22μF 20% RL 4X7
C117, C119 157D-475M-5-EI CE 16V 4.7μF 20% RL 3x5
C120 157D-226M-5-GM CE 16V 22μF 20% RL 4X7
C1201 150D-224K-J-BD CC 16V 0.22μF 10% 0805
C1202 150F-151K-J-BD CC 50V 150pF 10% 0805 1.
C1204 150D-224K-J-BD CC 16V 0.22μF 10% 0805
C1205 150F-471K-J-BD CC 50V 470pF 10% 0805
C1206 150D-224K-J-BD CC 16V 0.22μF 10% 0805
C1207 150F-151K-J-BD CC 50V 150pF 10% 0805 1.
C1208 150F-471K-J-BD CC 50V 470pF 10% 0805
C1209 150D-224K-J-BD CC 16V 0.22μF 10% 0805
C121 157D-226M-5-GM CE 16V 22UF 20% RL 4X7
ELECTRICAL PARTS LIST
Reference No. Part No. Description
