56
U125 3130-2020-3 IC 7805 REG 5V 1.5A
U131 3130-0890-0 IC NJM4558D DUAL OP AMP.
U134 3130-9560-0 NJM5532 IC 'DIP8'
SURROUND
AMP BOARD
2000 PCB-N0A00C-AMP2 SL/SR POWER AMP ASSEMBLY
CAPACITORS
C201 157F-106M-5-IUE CE 50V 10μF 20% RL 5X11
C202, C203 150F-101K-2-FC CC 50V 100pF 10% AT 3.5x
C204 150F-470K-2-GD CC 50V 47P 10% AT
C205 157C-227M-5-KW CE 10V 220μF 20% RL 6x12
C206, C207 157F-106M-5-IUE CE 50V 10μF 20% RL 5X11
C208 150F-223K-2-FD CC 50V 0.022μF 10% AT
C209 157F-106M-5-IUE CE 50V 10μF 20% RL 5X11
C210, C211 150F-101K-2-FC CC 50V 100pF 10% AT 3.5x
C212 150F-470K-2-GD CC 50V 47P 10% AT
C213 157C-227M-5-KW CE 10V 220μF 20% RL 6x12
C214, C215 157F-106M-5-IUE CE 50V 10μF 20% RL 5X11
C216 150F-223K-2-FD CC 50V 0.022μF 10% AT
C217, C218 150F-104K-2-FC CC 50V 0.1μF 10% AT
C220, C221 8910-0112-0 CE 63V 8200μF 20% RL
C223, C224 157I-477M-5-W&A CE 63V 470μF 20% RL 12.5
DIODES
D201-D204 4804-1480-C DIODE 1N4148 ATS
D205, D206 4804-0010-2 DIODE 1N4001 AT
D207 4804-1480-C DIODE 1N4148 ATS
D217 4840-7060-0 DIODE BRIDGE RS804M
WAFERS
J602A 2102-031S-004 3 PIN ST. WAFER
J702B 2102-051S-004 5P ST.WAFER
M704B 2101-9400-0 JM2422-3M WAFER
COILS
L201, L202 1804-0540-0 SPRING COIL 1MH
RELAY
M201 4500-0910-0 RELAY 24VDC,125VA,3A
WIRE CON ASSY
JP211 7012-6224-0 WIRE CON ASSY 4P P=3.96
P201 7012-6205-0 WIRE CON ASSY 3P P=3.96
TRANSISTORS
Q201, Q202 4860-0190-5 TR 2SC 1845 (F.E) RL
Q203 4860-8910-0 TR MPS A56 VCE 80V NS
Q204, Q205 4860-8890-0 TR MPS A06 VCE 80V NS
Q206 4860-8910-0 TR MPS A56 VCE 80V NS
Q207 4860-8890-0 TR MPS A06 VCE 80V NS
Q208 4860-5210-5 TR 2SC5198-0 HFE 80-160
Q209 4860-5220-5 TR 2SA1941-0 HFE 80-160
Q210, Q211 4860-0190-5 TR 2SC 1845 (F.E) RL
Q212 4860-0190-5 TR 2SC 1845 (F.E) RL
Q213 4860-8910-0 TR MPS A56 VCE 80V NS
Reference No.
Part No. Description
To Next Page
