NAD T 741 - Transformer; IC; Secondary Assembly Parts; Wire Assy

62
Q7724-Q7726 4860-8900-0 TR MPS A13 VCE 100V
Q7701-Q7726 4860-8910-0 TR MPS A56 VCE 80V NS
RESISTORS
R703, R705 4701-102J-C RCF 1/8W 1K 5% ATS
R704, R706 4701-104J-C RCF 1/8W 100K 5% ATS
R731 4701-102J-C RCF 1/8W 1K 5% ATS
R732 4701-333J-C RCF 1/8W 33K 5% ATS
R733, R724 4718-391J-2-X RMF 1W 390R 5% AT
R756, R757 4701-123J-C RCF 1/8W 12K 5% ATS
R7701-R7708 4701-103J-C RCF 1/8W 10K 5% ATS
R7709 4711-102A-2 RMF 1/8W 1K 1% AT
R7711-R7713 4701-681J-C RCF 1/8W 680R 5% ATS
R7714-R7719 4701-471J-C RCF 1/8W 470R 5% ATS
R7720-R7722 4701-100J-C RCF 1/8W 10R 5% ATS
R7723-R7725 4701-622J-C RCF 1/8W 6.2K 5% ATS
R7726-R7728 4701-512J-C RCF 1/8W 5.1K 5% ATS
R7729-R7735 4701-333J-C RCF 1/8W 33K 5% ATS
R7737-R7739 4701-121J-C RCF 1/8W 120R 5% ATS
R7740-R7742 4701-222J-C RCF 1/8W 2.2K 5% ATS
R7743-R7745 4701-122J-C RCF 1/8W 1.2K 5% ATS
R7746 4701-152J-C RCF 1/8W 1.5K 5% ATS
R7749-R7751 4715-331A-2 RMF 1/4W 330R 1% AT
R7752-R7759 4717-2R2J-C RMF 1/2W 2.2R 5% ATS
R7760-R7762 474B-R22K-5-02 RWR 5W 0.22R X2 10% RL
R7763-R7765 4701-272J-C RCF 1/8W 2.7K 5% ATS
R7766 4701-223J-C RCF 1/8W 22K 5% ATS
R7767-R7770 4701-473J-C RCF 1/8W 47K 5% ATS
R7771-R7773 4718-R22J-2 RMF 1W 0.22R 5% AT
R7774-R7776 4718-8R2J-2-X RMF 1W 8.2R 5% AT
R7777, R7778 4701-122J-C RCF 1/8W 1.2K 5% ATS
R7779, R7780 4701-512J-C RCF 1/8W 5.1K 5% ATS
R7781 4701-102J-C RCF 1/8W 1K 5% ATS
VR7701-VR7703 4756-1026-3-06 SVR 1K H3 7X7.6 RH0615C
THERMISTOR
TR7701 8910-0491-0 NTC THERMISTOR 1K (B)
ICs
U701 3131-4850-0 IC NJM5532M JRC (SMD)
U721, U7701 3130-2520-3 IC 7812 12V REGULATOR
U722 3130-3800-0 IC UPC79M12HF REGULATOR
U723 3130-8190-0 IC NJM78M56FA 5.6V
U726 3131-9110-0 IC 74HC08 AND GATES(SOP)
ZENERS
Z7701-Z7703 4837-10V6-2 DZ 1/2W 10V TEMIC AT
D722 4837-27V0-2 DZ 1/2W 27V(26.2-27.6)AT
MUL
TI CH ASSEMBLY
6300 PCB-N0A00C-MUTI MULTI CH ASSEMBLY
CAPACITORS
C601-C606 150F-101K-2-FC CC 50V 100pF 10% AT 3.5x
C6100, C6101 157F-106M-5-GM CE 50V 10μF 20% RL 4x7
Reference No.
Part No. Description
