NAD T 741 - Page 53

65
PSU
ASSEMBLY
7100 PCB-N0A01C-PSU PSU ASSEMBLYNA00C
CAPACITORS
C275 157E-227M-5-PU CE 25V 220μF 20% RL
C276 150F-223K-2-FD CC 50V 0.022μF 10% AT
C277 150F-103K-2-FC CC 50V 0.01μF 10% AT
C278 8910-0091-0 CC 400V 0.01μF +-20% RL
C503,C504 150F-102K-2-FC CC 50V 1000pF 10% AT 3.5
DIODES
D261-D264 *AH 4804-0040-1 DIODE IN4004 AL
D265 *C 4804-0040-1 DIODE IN4004 AL
WAFER / JACK
J201B 2102-051S-004 5P ST.WAFER
M268 2113-1179-0 PHONE JACK D3.5 BK
MISCELLANEOUS
P265 4131-9321-0 TERMINAL WRAP
P266 4131-9321-0 TERMINAL WRAP
M270,M272 *AH 4132-1011-0 FUSE HOLDER
M271 *C 4132-1011-0 FUSE HOLDER
RELAY
M273 4500-0890-0 RELAY 12VDC,250VAC,10A
TRANSISTOR
Q260 485C-123J-5 TR DTC123JSA ROHM
RESISTORS
R268 4701-103J-C RCF 1/8W 10K 5% ATS
R503,R504 4701-105J-C RCF 1/8W 1M 5% ATS
R501,R502 4701-331J-C RCF 1/8W 330R 5% ATS
R505 4701-820J-C RCF 1/8W 82R 5% ATS
TRANFORMER
T260 1806-2311-0 EI-35 TRANSFORMER 12V/AC
IC
U260 3130-2520-3 IC 7812 12V REGULATOR
SECONDARY ASSEMBLY
7200 PCB-N0A00C-SEC SECONDARY ASSEMBLY
CAPACITORS
C281,C282 153I-104J-5-NMN CM 63V 0.1μF RL (7.5X7)
C260,C262-C264 150F-104K-2-FC CC 50V 0.1μF 10% AT
WAFERS
J206A 2101-9400-0 JM2422-3M WAFER
J202B 2102-041S-004 4P ST.WAFER
WIRE ASSY
J704B 7703-1360-2004 CONN.ASSY 3P P205 L=360
Reference No.
Part No. Description
