NAD T 741 - Page 55

67
R516 4701-221J-C RCF 1/8W 220R 5% ATS
R517,R528,R536 4701-151J-C RCF 1/8W 150R 5% ATS
R519,R520,R537 4701-471J-C RCF 1/8W 470R 5% ATS
R521 4701-680J-C RCF 1/8W 68R 5% ATS
R522 4701-222J-C RCF 1/8W 2.2K 5% ATS
R523 4701-333J-C RCF 1/8W 33K 5% ATS
R524 4701-562J-C RCF 1/8W 5.6K 5% ATS
R525-R527 4701-102J-C RCF 1/8W 1K 5% ATS
R529 4701-122J-C RCF 1/8W 1.2K 5% ATS
R530 4701-822J-C RCF 1/8W 8.2K 5% ATS
R532-R535 4701-203J-C RCF 1/8W 20K 5% ATS
R538-R542 4701-102J-C RCF 1/8W 1K 5% ATS
R543-R546 4701-203J-C RCF 1/8W 20K 5% ATS
R547,R548 4701-471J-C RCF 1/8W 470R 5% ATS
R549,R588 4701-102J-C RCF 1/8W 1K 5% ATS
R550-R552 4701-103J-C RCF 1/8W 10K 5% ATS
SWITCH
SW501 5200-3171-0-01 DPDT SLIDE
IC
U501 3130-3840-0 IC 4052 QUAD ANALOG SW
ZENERS
Z501 4837-7C51-2 DZ 1/2W 7.29~7.67V ROHM
Z502 4837-7C51-2 DZ 1/2W 7.29~7.67V ROHM
SWITCH
ASSEMBLY
7800 PCB-N0A00C-SW SWITCH ASSEMBLY
POWER SWITCH
5200-3665-0 POWER SWITCH TV5
TUNER ASSEMBLY
9000 PCB-N0A01C-TUN TUNER ASSEMBLY
CAPACITORS
C381-C386 150F-101K-2-FC CC 50V 100pF 10% AT 3.5x
C902,C903 150F-223K-2-FD CC 50V 0.022μF 10% AT
C904 157D-106M-5-GM CE 16V 10μF 20% RL 4x7
C906 157D-107M-5-IU CE 16V 100μF 20% RL 5x11
C911 150F-200J-2-FC CC 50V 20pF 5% AT 3.5x2
C912,C913 150F-102K-2-FC CC 50V 1000pF 10% AT 3.5
C914,915,C945,C982 150F-101K-2-FC CC 50V 100pF 10% AT 3.5x
C916 150F-331K-2-FC CC 50V 330pF 10% AT 3.5x
C924,C925 15CH-200J-5-GG CTC 0/60 20pF 5% RL 4x4
C926 153F-333J-5-NLM CM 50V 0.033μF 5% RL 7.5
C927 157F-225M-5-GM CE 50V 2.2μF 20% RL 4x7
C928 157D-106M-5-GM CE 16V 10μF 20% RL 4x7
C929 157F-224M-5-GM CE 50V 0.22μF 20% RL 4x7
C930,C932,C941,C949 150F-223K-2-FD CC 50V 0.022μF 10% AT
C931 157B-107M-5-KM CE 6.3V 100μF 20% RL 6x7
C942 157D-107M-5-IU CE 16V 100μF 20% RL 5x11
C943 157F-225M-5-GM CE 50V 2.2μF 20% RL 4x7
C944 157F-475M-5-GM CE 50V 4.7μF 20% RL 4x7
C946 157F-105M-5-GM CE 50V 1μF 20% RL 4x7
Reference No.
Part No. Description
