5
DTS SECTION
Output Level (Vol 0 dB) : FL/FR/C/SL/SR Track 6 1 kHz 0.5 -0.2/+0.8 W
Channel Difference (FL ref) : FL/FR/C/SL/SR Track 6 1 kHz 0 ± 1.0 dB
Harmonic Distortion (Audio Filter) : FL/FR/C/SL/SR Track 10-14 1 kHz ≤ 0.08 %
Frequency Response (20 Hz to 20 kHz) Track 26-30 +2/-1.5 dB
Subwoofer Output Level 1 kHz ref at pre-out (FL) Play Track 10, charge to 15 12.5 ± 1.5 dB
AM TUNER SECTION
Input level is expressed as the reading in open circuit
of 75-ohm source impedance signal generator
Usable sensitivity (999/1000 kHz) ≤ 60 dBμV
S/N Ratio (5 mV in) ≥ 38 dB
THD (5 mV in) ≤ 3 %
IF Rejection (450 kHz) ≤ 36 dB
Image Rejection (F+2xIF) ≥ 28 dB
Selectivity ≥ 17 dB
Output 170 -20/+30 mV
Loop sensitivity (20 dB S/N)
999/1000 kHz ≤ 66 dB
603/600 kHz ≤ 66 dB
1404/1400 kHz ≤ 66 dB
Frequency Response (100 - 2.3 kHz, 5 mV) ± 6 dB
FM TUNER SECTION *C *AH
Input level is expressed as the reading in open circuit
of 75-ohm source impedance signal generator
Usable sensitivity (98 MHz) ≤ 15 dBμ ≤ 15 dBμv
S/N Ratio (60 dB, IHF wtd) Mono ≥ 60 dB ≥ 60 dB
Stereo ≥ 63 dB ≥ 63 dB
Frequency Response (20 Hz - 15 kHz, 60 dBμ) 0 ± 1.5 dB 0 ± 1.5 dB
Channel Separation (60 dBμ) 100 Hz ≥ 30 dB ≥ 30 dB
1 k ≥ 32 dB ≥ 32 dB
10 kHz ≥ 30 dB ≥ 30 dB
Alternate Channel Selectivity (40 dBμ, ± 400 kHz) ≥ 60 dB ≥ 45 dB
Capture Ratio (40 dBμ) ≤ 3 dB ≤ 3 dB
AM Suppression (60 dBμ, 100% Mod. FM, 30% Mod. AM) ≥ 48 dB ≥ 48 dB
Image Rejection (119.4 MHz) − ≥ 65 dB
I.F. Rejection (10.7 MHz) ≥ 78 dB −
Pilot Suppression (98 MHz) ≥ 50 dB ≥ 50 dB
THD (60 dBμ, L=R 75 kHz for AH, 40 kHz Dev for C) Mono ≤ 0.5 % ≤ 0.5 %
Stereo ≤ 0.5 % ≤ 0.5 %
Auto-Search Sensitivity On ≥ 24 dBμ ≥ 24 dBμ
Off ≤ 15 dBμ ≤ 15 dBμ
RDS decode Sensitivity ≤ 26 dBμ −
PHYSICAL SPECIFICATIONS
Dimensions (Width x Height x Depth) 435 x 180 x 431 mm
Net Weight 26.05 Kg (57.31 lbs)
Shipping Weight 31.1 Kg (68.42 lbs)
