Nagman MTC 650 User Manual

NAG/IM/MTC650/01/22 14
Passive Loop for 2 Wire :
Transmitter with Internal Power Supply (A for
Positive (+) and B for Negative (-))
Active Loop :
Transmitter with External Power Supply (B for
Positive (+) and C for Negative (-))
Voltage
B for Positive (+) and C for Negative (-)
* Note that this connection is for potential free contact.
Power Inlet Socket :
Input Supply 230V AC/50 Hz Standard;
110V AC/60 Hz Optional

Nagman MTC 650 Specifications

General

Brand	Nagman
Model	MTC 650
Category	Test Equipment
Language	English
