3/15 IOM-SDTU
Nailor Industries Inc. reserves the right to change any information concerning product or specification without notice or obligation.
Page 3 of 4
.40
.
02
.03
.04
.05
.
06
.07
.
08
.
09
.20
.
15
.50
.60
.70
.
80
.90
1
.0
.
30
4030 300 400 600 8001000 1500 4000 700030002000807050 200100 150
.10
CFM (standard air)
DIAMOND FLOW SENSOR
FIELD CALIBRATION CHART
MODEL SERIES
: 3
000, 3210, 35S-OAI & 38S
D
FSCC-1
10 - 09
SENSOR ∆P (INCHES W.G.)
S
I
Z
E
4
R
O
U
N
D
S
I
Z
E
5
R
O
U
N
D
S
I
ZE
6
R
O
U
N
D
S
I
Z
E
7
R
O
U
N
D
S
I
Z
E
8
R
O
U
N
D
S
I
ZE
9
R
O
U
N
D
S
I
Z
E
1
0
R
O
U
N
D
S
I
Z
E
1
2
O
V
A
L
S
I
Z
E
1
4
O
V
A
L
S
I
ZE
1
6
O
V
A
L
S
I
Z
E
2
4
x
1
6
R
E
C
T
.
A
LLOWABLE PNEUMATIC LO
SETTING MIN. ∆P = O.O3" W.G.
Inlet K-Factor
Size (std. air)
4 Round 182
5 Round 325
6 Round 455
7 Round 657
8 Round 899
9 Round 1158
10 Round 1497
12 Oval 2058
14 Oval 2554
16 Oval 3035
24 x 16 Rect. 6797
CFM = K x ∆P
3) Sample Calibration Label
– affixed near the control mounting panel. Shows airflow calibration data.
3) Airflow Direction Label
– affixed to the inlet collar (Supply Units)
or to the Flow sensor (Exhaust Units).
A
IR FLOW (ECOULEMENT DE L'AIR)
AIR FLOW (ECOULEMENT DE L'AIR)
L
OW (BAS) HIGH (HAUT)
HIGH (HAUT) LOW
Replacement Parts
Primary Damper Valve Part Number
Size 4", 5", 6" VB3-231
Size 7", 8" VB3-233
Size 9", 10" VB3-234
Size 12" VB3-235
Size 14" VB3-236
Size 16" VB3-237
Size 24"x16" VB3-238
Pneumatic FR Tubing (1/4" O.D.)
Black VB3-066
Blue stripe VB3-068
Red stripe VB3-067
Tee for Sensor Tap
Barbed, 1/8" VB3-058
Diamond Flow Sensor Part Number
Inlet Size
4" 3/16" O.D. tube V1104
5" 3/16" O.D. tube V1105
6" 3/16" O.D. tube V1106
7" 3/16" O.D. tube V1107
8" 3/16" O.D. tube V1108
9" 3/16" O.D. tube V1109
10" 3/16" O.D. tube V1110
12" 3/16" O.D. tube V1112
14" 3/16" O.D. tube V1114
16" 3/16" O.D. tube V1116
24"x 16" 3/16" O.D. tube V1124
Control Components
Analog - See Analog Operation Manual (IOM-AECVAV)
Cap for Sensor Tee
Rubber, for 1/8" Tee VB3-059
Recommended Maintenance
Single Duct Terminal Units supplied with stainless steel
construction are supplied with Celcon
®
bearings as standard.
Bronze oil impregnated bearings and 316 stainless steel
bearings are optional for certain applications. It is
recommended that those units equipped with 316 stainless steel
bearings be lubricated periodically as required by the application
and environment.
A Silicone based lubricant such as DuPont™ Pure Silicone
Lubricant with KRYTOX
®
PTFE or equivalent should be applied
to the shaft between the shaft and the bearing surface to
prevent excessive wear. This can be done without removal of
the shaft by pushing or pulling the shaft in one direction while
using a spray applicator tube to inject lubricant into the small
gap formed on the opposite side.
