E10
NAC 282 Preamplifier
11.4 NAC 282 Connected to Hi-Cap and NAPSC
mains input
and fuse
to stereo power ampliers
to mono or dual
mono power
ampliers
additional
signal out-
put
cable
direction
marker
240° 5 to 5 pin DIN
Interconnect Cables
12 NAC 282 Specification
Input Sensitivities: 75mV, 47kΩ
Overload Margins: 40dB
(all inputs all audio frequencies)
Main Output Level: 0.775V, <50Ω
Tape Output Level: 75mV, 600Ω
Auxiliary Power Outputs: For Naim phono stage.
Dimensions (H x W x D): 87 x 432 x 314mm
Weight: 7.0kg
Note: Alternative upgrade schemes and product
combinations may be feasible. Contact your local
representative or Naim Audio directly for further
information.
