E21
20.5 SUPERNAIT Connected to Hi-Cap Power Supply and NAP 200 Power Amplifier
mains input
and fuse
cable
direction
marker
4 to 4 pin DIN
Interconnect Cables
240° 5 to 5 pin DIN
mains input
and fuse
SUPERNAIT Integrated Amplifier
21 SUPERNAIT Specification
Input Sensitivities: 75mV, 47kΩ
Overload Margins: 40dB
(all inputs all audio frequencies)
Preamp Output Level: 0.775V, <50Ω
Tape Output Level: 75mV, 600Ω
Power Output: Continuous 80 Watts per
channel into 8 Ohms
Auxiliary Power Outputs: For Naim phono stage
Quiescent Consumption: 10VA
Dimensions (H x W x D): 87 x 432 x 314mm
Weight: 12.8kg
Mains Supply: 100-120V or 220-240V, 50/60Hz
mains
input
and fuse
power
