E27
26.2 NAIT 5i Rear
power
mains
input
and fuse
tuner input (DIN)
tuner input (RCA Phono)
CD input (DIN)
CD input (RCA
Phono)
hdd in
av in
27 NAIT 5i Specification
Input Sensitivities: 225mV, 20kΩ
Overload Margins: 35dB
(all inputs all audio frequencies)
Tape Output Level: 225mV, 100Ω
Power Output: Continuous 50 Watts per
channel into 8 Ohms
Quiescent Consumption: 10VA
Dimensions (H x W x D): 70 x 432 x 301mm
Weight: 6.4kg
Mains Supply: 100-120V or 220-240V, 50/60Hz
left
speaker
right
speaker
hdd out
ch1
-ve
nc
nc
ch2
cd and tuner
Inputs
NAIT 5i Integrated Amplifier
Note: The Nait 5i features various technologies to reduce
microphonic effects. Some movement of the board and
sockets when connecting and disconnecting cables is
normal.
