Flash Handset
17.1 Introduction
Flash is factory pre-programmed to operate any Naim
preamplifier or cd player, the NAT 05 tuner and AV2
audio-visual processor. Additional Naim sources may be
catered for in the future. Contact your dealer or local
representative for information.
Flash is supplied without batteries fitted. To fit the batteries,
remove the battery cover with the supplied hexagon driver and
slide the batteries into the handset body taking care with their
orientation. Replace the battery cover. Do not over-tighten the
fixing screw. With batteries fitted the handset is ready for use.
Flash is designed to switch off if unused after 10 seconds. It
switches on immediately if it is moved or a key is pressed.
17.2 Using Flash
Flash can be set to control each
equipment type through the
four
keys beneath the
display. The selected equipment
mode is indicated in the display
above each
key is pressed the
display and the eight
keys will
re-configure appropriately. The
display for each equipment type
shows a representation of the
eight
keys and their
functions.
The
key will also
wake an av processor from
standby. Press and hold the
key to return the
processor to standby mode.
The
keys are always available
to control the appropriate
(audio-visual or preamplifier)
volume and mute functions
regardless of the selected
source equipment mode.
The
equipment modes have multiple display “pages” (only one page
is necessary for Tuners). The first display page of each provides
control of the most commonly used functions, with subsequent
pages generally providing access to those less often used.
Selection of second and third pages within each mode is made
by pressing the appropriate
key. The currently selected
page is shown in the top right corner of the display. Details of
the
key functions within each page is described in the
following paragraphs:
PRE (preamplifier mode)
Page 1 of 2
Selects the next input source.
Selects the previous input source.
Adjusts balance to the left.
Adjusts balance to the right.
Enters programming mode on preamplifiers.
Selects display options on appropriately
equipped preamplifiers.
Sums the left and right channels.
Note: On Naim preamplifiers with no mono
facility, operates the tape monitor function.
Accesses a Flash setup page where source
labels can be chosen, and display preferences
can be set. Also provides access to RC5 setup.
Directly selects preamplifier input channels.
Page 2 of 2
The
However, selection of Page Two provides control of
the record functions on appropriately equipped preamplifiers.
CD (cd mode)
Page 1 of 2
Selects the previous track or index point
Selects the next track or index point
Cycles the cd player display through track,
time and off options.
Directly select CD tracks.
Page 2 of 2
The master key functions
play, stop, prev, next, rev
provides programming and repeat functions.
Enters CD track programming mode.
Repeats the CD or programmed tracks.
Selects CD tracks or index points for
programming.
TUN (tuner mode)
Page 1 of 1
Depending on the operational mode selected,
adjusts the tuning frequency upwards
, searches for stations up
the FM band
or selects the next
station preset
Operates in the same manner as the
Selects preset program mode that enables
FM stations to be assigned to preset memory.
Switches the tuner display on or off.
Combines the left and right channels
and may improve reception on weak signals.
Selects frequency, scan and preset modes.
Directly select station presets.
