20. Puck Identification
Three dierent pucks are used to clamp CDs in the players covered by this manual (CD555, CDX2, CD5 XS and CD5si). Only
the appropriate puck will work correctly in each player. The three pucks are illustrated below and their player applications
listed.
19. Diagram Icons
Analogue signal
Power switch
Digital signal
DIN/Phono socket selection switch
555PS Power Supply
Optional 555PS Power Supply
Optional XPS Power Supply
Optional FlatCap or Hi-CapPower Supply
RS232 Interface
180° DIN 5-pin
Cable direction indicator
IEC mains supply
RC5 remote control signal
20.1 CD555
20.2 CDX2, CD5 XS
20.3 CD5si
